Image preview - the first page of the document
service


>> Download service documenatation <<

Text preview - extract from the document
Micro System                                                                                                                     DCM2330/ALL




                               T
                               ABLE OF CONTENTS                                                                        Chapter
                                   Location of PC Boards & Versions Variation ........................ 1
                                  Technical Specifi ations................................. .................... 2
                                                 c
                                   safety instruction...................................................................3

                                  Set Block Diagram.................................................................4

                                  Set Wiring Diagram ...............................................................5

                                  Disassembly Diagram ...........................................................    6
                                  Main Board
                                     Circuit Diagram ................................................. ...........7-1
                                     Layout Diagram.............................................................. 7-2
                                  Display Board
                                     Circuit Diagram................................................................8-1
                                     Layout Diagram ...............................................................8-2
                                   IPOD Board
                                     Circuit Diagram ............................................................... 9-1
                                     Layout Diagram                                                                  9-2
                                                               ...............................................................


                                  Mechanical Exploded View ..................................................10
                                  Trouble Shooting.......................................................11
                                  Software Upgrade & Procedure To Restore Product Setting....12
                                  Revision list ......................................................................... 13




   Copyright 2013 WOOX Innovations Limited.
All rights reserved. No part of this publication may be reproduced, stored in
a retrieval systemor transmitted, in any form or by any means, electronic,
mechanical, photocopying, or otherwise without the prior permission of
WOOX Innovations. Philips and the Philips'Shield Emblem are registered
trademarks of Koninklijke Philips N.V. and are used by WOOX Innovations
Limited under license from Koninklijke Philips N.V.


Published by Liu wk1416 Subject to modification                                                                                   3140 038 61770


Version 1.0
               1.Location of PC Boards & Versions Variation

               Boards
Location of PC Boards
Location




Display Board



 Main Board




   Versions Variation

                            Type/Version          DCM2330
       Board in used       Service Policy   /12

       Main board                           M+C
       Display board                        M+C




       Tips: C--Component Level Repair
             M--Module Level Rpair
     2   TechnicalSpecifcatons


DCM2330

TEST CONDITIONS:

1.POWER SUPPLY: AC.Accordiing to Ver

2.REF OUTPUT: 4 1W , Sound effect off

3.FM MONO: 22.5KHz Dev,1KHz MODULATION ,75 IMPEDANCE ,60dBu

4.FM STEREO : MAIN+SUB = 50KHz, PILOT : 10KHz,COMPOSITE: 40.0KHz

FM SECTION

                                                                                        TEST DATA
NO                     TEST ITEMS                     UNIT   NOM.   LIMIT
                                                                               1#           2#          3#

                                                                    87.5      87.5         87.5        87.5
 1              Fvequency Range                       MHz
                                                                    108       108           108        108

                                               88             18     22        14           14          14

 2         26dB QUENTING SENSITIVITY           98      dBf    18     22        14           14          14

                                              107             18     22        15           15          15

 3            -3dB LIMITING POINT              98      dBf    20     26        8             8           7

 4       FM IF REJECTION 98MHZ S/N=26dB        98      dB     55     50        70           70          71

 5        IMAGE REJECT 98MHZ S/N=26dB         107      dB     24     20        70           70          71

                                             MONO             55     50        68           69          70
 7                    S/N
                                              ST              55     50        66           66          66

 8            OVERALL DISTERTION                       %       2     3        0.2           0.2         0.1

 9             MODULATION HUM                          dB     50     45        67           63          71

                                             88MHz     dBf    30     25        23           23          21

11               TUNING SENS                 98MHz     dBf    30     25        23           23          21

                                            107MHz     dBf    30     25        24           24          24

15              THD 10% POWER                          W                    10.6/10.6    10.1/10.1   10.6/10.6
CD SECTION

                                                                                                   TEST DATA
NO                     TEST ITEMS                           UNIT   NOM.   LIMIT
                                                                                     1#           2#          3#

1        TOTAL HARMONIC DISTORTION                 1KHz      %     1.5    2         0.1           0.1         0.2

2                  S/N (1KHz,A-weightde)                    dBA     76     70        80           80          80

     FREQUENCY RESPONSE AT                         63Hz     dB
