Image preview - the first page of the document
service


>> Download service documenatation <<

Text preview - extract from the document
DVD Micro System                                                                                                                                             DCM377
                                                                                                                                                                        /12/05




Contents                                                             Page             Contents                                                               Page
1 Technical Specification and Connection Facilities and                               15 Output Board
  Version Variation .............................................1-1 to 1-2
                                                                                                     Circuit Diagram .................................14-2
2 Laser Beam Safety Precautions.................................2-1                                  Layout Diagram ................................14-3
3 Important Safety Precautions ..........................3-1 to 3-2                   16 Power Socket and LED Board
4 Safety Check After Servicing .................................... 4-1                             Circuit Diagram .................................14-4
5 Safety Information General Notes & Lead Free                                                       Layout Diagram ................................14-4
  Requirements ............................................................5-1        17 VFD Display Board
6 Standard Notes For Servicing,Lead Free Requirements                                                 Circuit Diagram ...............................14-5
  & Handling Flat Pack IC ..................................6-1 to 6-4                                Layout Diagram ...............................14-6
7 Direction of Use ...............................................7-1 to 7-5          18 MCU Board
8 Cabinet Disassembly Instructions ................... 8-1 to 8-3                                             Circuit Diagram ..............................14-7
                                                                                                              Layout Diagram .............................14-8
9 Troubleshooting ....................................................... 9-1
10 Software Version Check &Upgrad..............10-1 to 10-2                            19 Decoder Board
                                                                                                      Circuit Diagram ..............................14-9 to 14-20
11 Repair Service Flow....................................11-1 to 11-6
                                                                                                      Layout Diagram .............................14-21
12 Block Diagram ........................................................12-1
                                                                                       20 Power Board
13 Wiring Diagram ...................................................... 13-1                                 Circuit Diagram ..............................14-22
14 Touch Key Board                                                                                            Layout Diagram .............................14-23
               Circuit Diagram .................................14-1
               Layout Diagram ................................14-1                    21 Exploded View......................................................15-1
                                                                                       22 Revision List .........................................................16-1
