Image preview - the first page of the document
>> Download service documenatation <<
Text preview - extract from the document
DTM5096
wk1505
Version 2.0
1.Location of PC Boards & Versions Variation
Location of PC Boards
USB Board
BT Board
BT LED AUDIO IN
Board Board
Key Board
Main Board CD Board
Location of PC Boards
SMPS Board FM-ANT Board
Versiongs Variation
Type/Version DTM5096
/12 /12
Board in used service Policy (EU) (APMEA)
KEY Board M M+C
BT Board M M+C
BT LED Board M M+C
USB Board M M+C
AUIDO IN Board M M+C
Main Board M M+C
CD Board M M+C
SMPS Board M M+C
FM-ANT Board M M+C
Tips:C--Component Level Repair
M--Module Level Rpair
2.Technical Specification
MODEL DTM5096
FM
FM Electrical Specification & Data
Supply see version table Ref.o/p 500 mW O/P imped : R/L , LS 6 ohm , Woofer 6 ohm
Condition
Description Unit Nor Limit Data Data
See version table
1 Band coverage MHz
-sh190
2 Intermediate Frequency MHz 128KHz
3 26dB 26dB quieting sensitivity 90/98/106 MHz dBuf 18 22 21 21
4 46dB 46dB sensitivity (Stereo) 40kHz dev dBuf 46 49 46 46
5 I.F. rejection dB 65 60 60 61
6 Image rejection dB 25 20 22 22
7 -3dB -3dB limiting PT. dBuV 17 23.5 21 21
8 AM supression Input 100uV~5mV,22.5kHzdev dB 30 25 30 30
1mV ,22.5kHz dev,
9 -3dB -3dB AFC holding range
lower to upper range
kHz \ \ \ \
10 Adjacent channel selectivity +/-400KHz dB 40 33 40 40
11 Overall distortion 100uV~4mV,75kHz dev % 4 7 4 5
75kHz dev, ref o/p with
12 Large signal handling dBuV 116 108 108 108
10% THD
13 8X,9X,10X harmonics whistle 10uV~1mV,22.5kHz dev dB 35 30 35 35
Overall frequence response - 50us(For EUR) Hz 300 1.2 1.2
14
(1kHz ref) (1kHz ref) - 75us (For USA) Hz 8K 2 2
10% Output power At 10% THD 1KHz FRONT R / L W 40 32 30 30
15 67.5kHz dev Living sound on 1KHz LIVING SOUND W 20 16 11 12
100Hz SUB - WOOFER W 70 56 60 61
16 Distortion 1mV, 22.5kHz dev % 1 3 1 1
17 S/N ratio 1mV,75kHz dev dB 50 45 61 61
18 Modulation hum 1mV ,22.5kHz dev dB 55 45 50 55
19 Amplification reserve dB \ \ \ \
20 ( - 20dB Hum Vol. max. -20dB mV 2 6 0.8 0.8
21 Stereo On pont Pilot dev : 6kHz dBuV 9.5 28 29 29
22 Stereo Off pont dbuV Switching On -6dB / /
Channel separation 1mV ,40kHz dev
23 dB 26/30/20 20/26/18 25/28/22 25/28/22
(400 / 1000 / 5000) (400 / 1000 / 5000Hz) W/A FILTER
Channel unbalance
24 1mV ,22.5kHz dev dB 0 3 0.2 0.2
(250 to 6300Hz) (250 to 6300Hz)
25 120V setting V 96 N/A N/A
Osc. stop voltage 230V setting V 184 N/A N/A
-10<--->10 kHz/ N/A N/A
26 () Frequency drift vs. temp. 30<--->50 kHz/ N/A N/A
10<--->30 kHz/ N/A N/A
27 Search tuning sensitivity dBuV 16 to 28 11 to 35 32/34/35 32/34/35
Vin >14.2mV,Step <= 50kHz
28 arch tuning stop accuracy Step 0 +/- 1 N/A N/A
Other condition
87.5 to 108MHz <= 60
29 time of total tuning range S N/A N/A
65.81to74 & 87.5to108MHz <= 100
30 Max output 1mV, 75kHz dev V For reference only
N/A N/A
31 (DC in ) Currnet consumption min. / max. vol. 67.5kHz Refer to sh190
32 RDS RDS sensitivity 40kHz dev dBuV 28 35 N/A N/A
CD
CD Electrical Specification & Data
Audio part (measured with Audio Signal 1 disc - SBC429, 20 to 20k Hz filter)
Supply see version table Ref.o/p 500 mW O/P imped : R/L , LS 6 ohm , Woofer 6 ohm
Description Condition Unit Nor Limit Data Data
Channel balance FRONT R / L dB 0 2 0.1 0.1
1
LIVING SOUND dB 0 2 N/A N/A
THD (10KHz / 1KHz) FRONT R / L % 2.0 / 1.0 3.0 / 1.5 0.5 0.5
2 LIVING SOUND % 2.0 / 1.0 3.0 / 1.5 1.0 1.0
100Hz SUB - WOOFER % 2.0 / 1.0 3.0 / 1.5 0.57 0.57
Crosstalk 1K FRONT R / L dB 45 / 40 30 / 30 74 74
3
LIVING SOUND dB 45 / 40 30 / 30 N/A N/A
300 to 20kH FRONT R / L dB 0 +/- 3 -1.7 -1.7
4 Frequency response 300 to 20KHz LIVING SOUND dB 0 +/- 3 -1 -1
60 to 250Hz SUB - WOOFER dB 0 +/- 3 -2 -2
10% Output power At 10% THD 1KHz FRONT R / L W 40 32 35.5 35
5 1 kHz 0 dB Living sound on 1KHz LIVING SOUND W 20 16 11 11
100Hz SUB - WOOFER W 70 56 62 62
TNO 15 & TNO 49
SNR unwtd. dB \ \ \ \
(line out)
6
TNO 15 & TNO 49
dB \ \ \ \
(speaker out)
SNR wtd. DBA FRONT R / L dBA 80 75 88 88
7 LIVING SOUND dBA 62 57 84 84
SUB - WOOFER dBA 62 57 91 91
8 Amplification reserve TNO 35 (1 KHz -6dB) dB \ \ \ \
( - 20dB) hum FRONT R / L mV 1 3 0.6 0.6
9 LIVING SOUND mV 1 3 0.5 0.5
Vol. max. -20dB to vol. Min SUB - WOOFER mV 1 3 0.5 0.5
() Min volume (residual) noise FRONT R / L mv 0.6 0.8 0.2 0.2
10 LIVING SOUND mv 0.6 0.8 0.2 0.2
SUB - WOOFER mv 0.6 0.8 0.2 0.2
11 Max output -20db / -0dB V For reference only
USB
USB Electrical Specification & Data
Supply see version table Ref.o/p 500 mW O/P imped : R/L , LS 6 ohm , Woofer 6 ohm
Audio part (measured use Scan Disk USB driver,test signal copy from Audio Signal 1 disc - SBC429 data
Description Condition Unit Nor Limit Data Data
Channel balance FRONT R / L dB 0 2 0.2 0.2
1
LIVING SOUND dB 0 2 N/A N/A
THD (10KHz / 1KHz) FRONT R / L % 2.0 / 1.0 3.0 / 1.5 0.8 0.8
2 LIVING SOUND % 2.0 / 1.0 3.0 / 1.5 1.2 1.2
100Hz SUB - WOOFER % 2.0 / 1.0 3.0 / 1.5 0.9 0.9
FRONT R / L dB 45 / 40 30 / 30 65 65
3 osstalk 1K
LIVING SOUND dB 45 / 40 30 / 30 N/A N/A
300 to 20kHz FRONT R / L dB 0 +/- 3 3 3
4 Frequency response 300 to 20KHz LIVING SOUND dB 0 +/- 3 3 3
60 to 250Hz SUB - WOOFER dB 0 +/- 3 1.2 1.2
10% Output power At 10% THD 1KHz FRONT R / L W 40 32 30 30
5 1 kHz 0 dB Living sound on 1KHz LIVING SOUND W 20 16 11 11
100Hz SUB - WOOFER W 70 56 61 61
TNO 15 & TNO 49
dB \ \ \ \
(line out)
6 NR unwtd.
TNO 15 & TNO 49
dB \ \ \ \
(speaker out)
FRONT R / L dBA 80 75 88 88
7 SNR wtd. DBA LIVING SOUND dBA 62 57 87 87
SUB - WOOFER dBA 62 57 80 80
8 Amplification reserve TNO 35 (1 KHz -6dB) dB \ \ \
FRONT R / L mV 1 3 0.6 0.6
( - 20dB
9 hum LIVING SOUND mV 1 3 0.6 0.6
Vol. max. -20dB to vol. Min SUB - WOOFER mV 1 3 0.5 0.5
() Min volume (residual) noise FRONT R / L mv 0.6 0.8 0.2 0.2
10 LIVING SOUND mv 0.6 0.8 0.2 0.2
vol = 0 mute no active SUB - WOOFER mv 0.6 0.8 0.1 0.1
11 Max output -20db / -0dB V For reference only N/A N/A
AUDIO IN
AUDIO IN Electrical Specification & Data
Supply see version table Ref.o/p 500 mW O/P imped : R/L , LS 6 ohm , Woofer 6 ohm
Audio part (Input 1KHZ 500mv ,test signal copy from Audio Signal 1 disc - SBC429 data)
Description Condition Unit Nor Limit Data Data
1 Input sensitivity mV \ \ 500MV 505MV
Channel unbalance FRONT R / L dB 0 3 0 0
2
LIVING SOUND dB 0 3 N/A N/A
300 to 20kHz FRONT R / L dB 0 +/- 3 -3 -3
3 Frequency response 300 to 20KHz LIVING SOUND dB 0 +/- 3 3 3
60 to 250Hz SUB - WOOFER dB 0 +/- 3 2.2 2.2
Channel separation FRONT R / L dB 40 30 52 52
4
LIVING SOUND dB 40 30 N/A N/A
500mV THD (10KHz / 1KHz) FRONT R / L % 0.2/1 1/3 0.16 0.17
5 LIVING SOUND % 0.2/1 1/3 0.18 0.19
100Hz SUB - WOOFER % 0.2/1 1/3 0.19 0.19
10% THD output FRONT R / L W 40 32 30 30
6 10 power LIVING SOUND W 20 16 10 10
500MV SUB - WOOFER W 70 56 62 63
FRONT R / L dB 80 75 88 88
7 S/N wtd. DBA LIVING SOUND dB 62 57 87 87
SUB - WOOFER dB 62 57 80 80
( - 20dB) Hum FRONT R / L mV 1 3 0.6 0.6
8 LIVING SOUND mV 1 3 0.5 0.5
Min volume (residual) noise SUB - WOOFER mV 1 3 0.5 0.5
() FRONT R / L mV 0.6 0.8 0.2 0.2
9 Min volume (residual) noise LIVING SOUND mV 0.6 0.8 0.2 0.2
SUB - WOOFER mV 0.6 0.8 0.1 0.1
Headphone Electrical Specification & Data
Description Condition Unit Nor Limit Data Data
Headphone
1 10 10% THD output power
impedance 32 ohm
mW 8 8.7 8.8
AUX 500MV ( 1 KHz ) dB 0 +/-3 0 0.1
CD 1K -6 db dB 0 +/-3 1.5 1.5
2 Level Matching USB 1K -6 db dB 0 +/-3 0.8 0.9
FM 1K MOD: 67.5DEV dB 0 +/-3 -2.2 -2.3
IPOD 4G / I-PHONE
1K 0db
dB 0 +/-3 0 0
I-PHONE / IPOD (I-PHONE 5)
I-PHONE 5 Electrical Specification & Data
Supply see version table Ref.o/p 500 mW O/P imped : R/L , LS 6 ohm , Woofer 6 ohm
Audio part (test signal copy from Audio Signal 1 disc - SBC429 ) data setting will be TBC
Description Condition Unit Nor Limit Data Data
Channel balance FRONT R / L dB 0 2 0.2 0.2
1
LIVING SOUND dB 0 2 N/A N/A
THD (10KHz / 1KHz) FRONT R / L % 2.0 / 1.0 3.0 / 1.5 0.25 0.26
2 LIVING SOUND % 2.0 / 1.0 3.0 / 1.5 0.3 0.3
100Hz SUB - WOOFER % 2.0 / 1.0 3.0 / 1.5 0.2 0.2
Crosstalk 1K FRONT R / L dB 45 / 40 30 / 30 73 75
3
LIVING SOUND dB 45 / 40 30 / 30 N/A N/A
TNO200 to10KHz16KHz = FRONT R / L dB 0 +/- 3 3 3
4 Frequency response 200 to10KHz16KHz = LIVING SOUND dB 0 +/- 3 2.2 2.2
40 to 150Hz SUB - WOOFER dB 0 +/- 3 1.2 1.2
10% Output power At 10% THD 1KHz FRONT R / L W 40 32 32 32
5 1 kHz 0 dB Living sound on 1KHz LIVING SOUND W 20 16 10.6 10.6
125Hz SUB - WOOFER W 70 56 62 63
TNO 15 & TNO 49
dB \ \ N/A N/A
(line out)
6 NR unwtd.
TNO 15 & TNO 49
dB \ \ N/A N/A
(speaker out)
FRONT R / L dBA 80 75 88 89
7 SNR wtd. DBA LIVING SOUND dBA 62 57 88 89
SUB - WOOFER dBA 62 57 89 89
8 Amplification reserve TNO 35 (1 KHz -6dB) dB \ \ N/A N/A
( - 20dB) hum FRONT R / L mV 1 3 0.5 0.5
9 LIVING SOUND mV 1 3 0.6 0.6
Vol. max. -20dB to vol. Min SUB - WOOFER mV 1 3 0.5 0.5
() FRONT R / L mv 0.6 0.8 0.2 0.2
10 Min volume (residual) noise LIVING SOUND mv 0.6 0.8 0.1 0.1
SUB - WOOFER mv 0.6 0.8 0.1 0.1
11 Max output -20db / -0dB V For reference only N/A N/A
BLUE TOOTH
BT Electrical Specification & Data
Supply see version table Ref.o/p 500 mW O/P imped : R/L , LS 6 ohm , Woofer 6 ohm
Audio part (test signal copy from Audio Signal 1 disc -SBC429) data setting will be TBC
Description Condition Unit Nor Limit Data Data
Channel balance FRONT R / L dB 0 2 0.2 0.2
1
LIVING SOUND dB 0 2 N/A N/A
THD (10KHz / 1KHz) FRONT R / L % 2.0 / 1.0 3.0 / 1.5 0.5 0.5
2 LIVING SOUND % 2.0 / 1.0 3.0 / 1.5 0.2 0.2
100Hz SUB - WOOFER % 2.0 / 1.0 3.0 / 1.5 0.6 0.6
Crosstalk 1K FRONT R / L dB 45 / 40 30 / 30 75 77
3
LIVING SOUND dB 45 / 40 30 / 30 N/A N/A
TNO200 to10KHz16KHz = FRONT R / L dB 0 +/- 3 2.2 2.2
4 Frequency response 200 to10KHz16KHz = LIVING SOUND dB 0 +/- 3 1.2 1.3
40 to 150Hz SUB - WOOFER dB 0 +/- 3 1 1
10% Output power At 10% THD 1KHz FRONT R / L W 40 32 33 33
5 1 kHz 0 dB Living sound on 1KHz LIVING SOUND W 20 16 11 11
125Hz SUB - WOOFER W 70 56 62 64
TNO 15 & TNO 49
SNR unwtd. dB \ \ N/A N/A
(line out)
6
TNO 15 & TNO 49
(speaker out)
dB \ \ N/A N/A
SNR wtd. DBA FRONT R / L dBA 80 75 88 89
7 LIVING SOUND dBA 62 57 87 88
SUB - WOOFER dBA 62 57 88 88
8 Amplification reserve TNO 35 (1 KHz -6dB) dB \ \ N/A N/A
( - 20dB) hum FRONT R / L mV 1 3 0.5 0.5
9 LIVING SOUND mV 1 3 0.6 0.6
Vol. max. -20dB to vol. Min
SUB - WOOFER mV 1 3 0.6 0.6
() FRONT R / L mv 0.6 0.8 0.1 0.1
10 Min volume (residual) noise LIVING SOUND mv 0.6 0.8 0.2 0.2
SUB - WOOFER mv 0.6 0.8 0.2 0.2
11 Max output -20db / -0dB V For reference only N/A N/A
3.Safety instruction
1. General safety
2.Laser safety
Safety regulations require that during a repair:
This unit employs a laser. Only qualified service personnel
. Connect the unit to the mains via an isolation transformer.
may remove the cover, or attempt to service this device
. Replace safety components indicated by the symbol ,
(due to possible eye injury).
only by components identical to the original ones. Any
Laser device unit
other component substitution (other than original type)
Type : Semiconductor laser GaAlAs
may increase risk of fire or electrical shock hazard.
Wavelength : 650nm (DVD)
: 780nm (VCD/CD)
Safety regulations require that after a repair, you must
Output power : 7mW (DVD)
return the unit in its original condition. Pay, in particular,
: 10mW (DVD /CD)
attention to the following points:
Beam divergence: 60 degree
. Route the wires/cables correctly, and fix them with the
Note: Use of controls or adjustments or performance of
mounted cable clamps.
procedure other than those specified herein, may result in
. Check the insulation of the mains lead for external
hazardous radiation exposure. Avoid direct exposure to
damage.
beam.
. Check the electrical DC resistance between the mains
plug and the secondary side:
1) Unplug the mains cord, and connect a wire between
the two pins of the mains plug.
2) Set the mains switch the "on" position (keep the
mains cord unplug).
3) Measure the resistance value between the mains
plug and the front panel, controls, and chassis
bottom.
4) Repair or correct unit when the resistance
measurement is less than 1M .
5) Verify this, before you return the unit to the
customer/user (ref. UL-standard no. 1492).
6) Switch the unit "off", and remove the wire between
the two pins of the mains plug.
-28V/0.3A
f(x1...xn)
Commutate x1 3.5V/0.3A
u1
&Filter
x2
5.2V/2.1A
6.5V/1.5A
GND
AMP_30V/5A
AMP_GND
Power Ctrl&Standby
L
R
ANT 32.768KHz
Switch+ADC PERSET- Power L
L/R
CE2631 EQ+VOLUNE Amplifier
R
STA326(30Wx2ch)
DSP PERSET- Power
C
CS48540 EQ+VOLUNE Amplifier
STA326(30W+70W)
SW
ANT
24MHZ
IR-Receiver
USB Audio+
DM System CPU
DP OTK5250 Touch Key x 10
GT1000A
16.93MHZ
SPI Flash
16M SDRAM
GD25Q80
SPI
VFD Driver VFD Display
* MP3/WMA decoder VFD20-1033
ET16315
* CD DSP+RF Amp
* ESP
5.Set Wiring Diagram
6.DISMANTLING DIAGRAM
1)Dismantling of the top cabinet:
a.Remove 8 screws A&B as indicated to loosen the back cabinet
A
B
b.Remove 2 screws C as indicated to loosen the top cabinet
C
c.Remove 8 screws D,E&F as indicated to loosen the top cabinet
F
D
E
2)Dismantling the PCB board of the top :
a: Remove 3 screws G as indicated to loosen the BT board
b: Remove 4 screws H as indicated to loosen the Key board
c: Remove 2 screws I as indicated to loosen the BT-LED board
H
G
I
d: Remove 4 screws J as indicated to loosen the Main board
e: Remove 3 screws K as indicated to loosen the CD board
K
J
f: Remove 1 screws L as indicated to loosen the USB&AUDIO IN board
g: Remove 2 screws M as indicated to loosen the IR board
L
M
3)Dismantling of the bottom cabinet:
1.Remove 10 screws O&P as indicated to loosen the back cabinet
O
P
2)Dismantling the PCB board of the Bottom :
a: Remove 4 screws Q as indicated to loosen the SMPS board
b: Remove 2 screws R as indicated to loosen the FM-ANT board
Q
R
7-1.Main Board Circuit Diagram
Main Board Circuit Diagram
Main Board Circuit Diagram
7-2.Main Board Layout Diagram
Main Board Layout Diagram
Main Board Layout Diagram
Main Board Layout Diagram
Main Board Layout Diagram
Main Board Layout Diagram
BT Board Layout Diagram
BT Board Layout Diagram
Iphone4 Board Layout Diagram
Iphone4 Board Layout Diagram
Iphone5 Board Layout Diagram
Iphone5 Board Layout Diagram
Input Board Layout Diagram
Input Board Layout Diagram
8-1.SMP Board Circuit Diagram
1 2 3 4 5 6 7 8
AC IN !
HV
L N 3.96*3 C16 1.5uF/250V TR2
! ! ! RL207*4
D17
DD1
L1
CN4 LF1 LF2 +30V
CX1
51R/3W
UF16 UF16
120u/200V
R40 360K R31 360K
C12
F2.5A L250V
3.96*3 R30 D23 C10 R43
CN3
R33
10241
TVR2 2.7K/1W
F1 D13 51R/1W 1000uF/35V
D
! U
GND D
! D16 !
C13 4.7uF/50V
47uF/50V
RT1 C11
C15
120u/200V
R35 GND
222/1KV
C17 D24
10241
00504 0.1uF/275V TVR3 TR1
FR107
2R 222 C29
RA12
RA10
U
DD1 RB6 RB21
R34 10R T7 -30V
D10 R36 13007 2R 100R
1N4148 2.7K D15
D14 T1
RA9
RA11
RA8 D28
C14 4.7uF/50V
R38
RA7 R41 DW1 2R D11 RB7
FR107 5VSB
510R R37 10R T6 330R
D12 R39
! C7
15V/0.5W
1N4148 2.7K
13007
! GND U2B
U2A
817
1uF25V R18 D29
817 !
1.5K CY1
GND 1000pF/250V GND
T3 RB12
PSON
1815 1815 5.1K
D18
D9 D8
1N4148 T4 1N4148 T5
C 13 14 1N4148 C
R6 1815
C4 5.1K 1% GND
D3
4.7uF/50V
1N4148 12
4 SB560 L3
D27 Q4/Q5
C9 1N4148
R17 R13 D7 6.5V
R4 2
R11 R2 R3 2.7K 2.7K
4.7uF/50V
1000u/16V
C39
470uf/16V
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
