Image preview - the first page of the document
>> Download fw_c380_partslistcassette_257 documenatation <<
Text preview - extract from the document
9-9 9-9
TAPE MODULE EXPLODED VIEW TAPE MECHANISM - MOTOR EXPLODED VIEW
1 3139 118 77130 Autoreverse Mech. CWE44FR01 31 4822 361 11055 Motor Assembly
1 3139 118 77140 Non-Autoreverse Mech. CWE44FF02 Chrome/Ferro 91 - Screw M2,6 x 5
1 3139 118 77950 Non-Autoreverse Mech. CWE44FF05 Ferro 92 - Screw M2 x 5
3 - Screw D3 x 10
6 - Screw M2 x 16 Note: Only the parts mentioned in this list are normal
7 3139 110 34080 Flex Cable 14 pin 7,5 cm service spare parts.
Note: Only the parts mentioned in this list are normal service spare parts.
9-10 9-10
TAPE MECHANISM A - PLAY
MECHANICAL PARTS - PLAY MECHANISM
1 9965 000 02313 Play Head (Non-Autoreverse deck)
1 9965 000 02321 Play Head (Autoreverse deck)
12 4822 402 10972 Pinch Arm Assembly R
23 9965 000 02314 Coil Assembly
25 9965 000 06443 Cam Gear
32 4822 528 11209 Flywheel Assembly RV
42 9965 000 02315 Belt AF (Autoreverse deck)
42 9965 000 02718 Belt AF (Non-autoreverse deck)
69 4822 492 11761 Spring
102 4822 532 12931 Washer
103 4822 532 12932 Washer
104 4822 532 12933 Washer
Note: Only the parts mentioned in the list are normal service
spare parts.
9-11 9-11
TAPE MECHANISM B - RECORD/PLAYBACK (Non-Autoreverse version)
MECHANICAL PARTS - REC/PB MECHANISM
1 9965 000 02313 Play Head
3 9965 000 02600 Head, Erase
12 4822 402 10972 Pinch Arm Assembly R
23 9965 000 02314 Coil Assembly
25 9965 000 06443 Cam Gear
32 4822 528 11209 Flywheel Assembly RV
44-2 9965 000 02317 Flex Socket 14 Pin
44-3 9965 000 02320 Photo Interrupter
44-4 4822 050 16801 680R 1% 0,4W
44-6 9965 000 02318 Leaf Switch
44-7 9965 000 02319 Mode Switch
59 9965 000 02719 Belt BF (Large)
69 4822 492 11761 Spring
102 4822 532 12931 Washer
103 4822 532 12932 Washer
104 4822 532 12933 Washer
Note: Only the parts mentioned in the list are normal service
spare parts.
9-12 9-12
TAPE MECHANISM B - RECORD/PLAYBACK (Autoreverse version)
MECHANICAL PARTS - REC/PB MECHANISM
12 4822 402 10972 Pinch Arm Assembly R
23 9965 000 02314 Coil Assembly
25 9965 000 06443 Cam Gear
32 4822 528 11209 Flywheel Assembly RV
39 9965 000 02322 Belt AF
44-2 9965 000 02317 Flex Socket 14 Pin
44-3 9965 000 02320 Photo Interrupter
44-4 4822 050 16801 680R 1% 0,4W
44-6 9965 000 02318 Leaf Switch
44-7 9965 000 02319 Mode Switch
45 9965 000 02323 Rec/Pb Head Assembly
50 4822 402 10973 Pinch Arm Assembly L
54 9965 000 02324 Flywheel Assembly L
69 4822 492 11761 Spring
73 4822 492 11762 Spring
101 9965 000 02325 Washer
102 4822 532 12931 Washer
103 4822 532 12932 Washer
104 4822 532 12933 Washer
107 9965 000 02326 Washer
109 9965 000 02327 Washer
Note: Only the parts mentioned in the list are
normal service spare parts.
