Image preview - the first page of the document
FX55


>> Download FX55 documenatation <<

Text preview - extract from the document
   Mini Speaker                                                                                                                   FX 55/77/12




                                      TABLE OF CONTENTS
                                                                                                                          Page
                                      Location of PC Boards & Versions Variation ........................ 1
                                      Specifications ....................................................................... 2
                                      Safety Instruction .................................................................. 3
                                      Software Upgrade Instruction..................................................4
                                      Troubleshooting.................................................................... 5
                                      Disassembly Instructions ..................................................... 6
                                      Set Block & Wiring Diagram ................................................. 7
                                      Circuit Diagram & PCBA Layout........................................... 8
                                      Set Mechanical Exploded View .......................................... 9
                                      Revision List ........................................................................ 10




Published by Niki &Kelly WK1431 Subject to modification                                                                                   3140 038 62270
                                               1


            PCB Board Locations
FRONT CONTROL BOARD                                                 NFC BOARD

USB BOARD                                                            KEY BOARD

IN BOARD                                                            SUPPORT BOARD
                                  Inside the front panel




 LOADER                                                             POWER BOARD


 MAIN BOARD

                                  On the bottom plate




              VERSION VARIATIONS
                             Type / Versions                 FX55

              Board in used   Service Policy       /77     /12
              MAIN BOARD                           C       M
              POWER BOARD                          C       M
              FRONT CONTROL BOARD                  C       M
              BLUETOOTH BOARD                      C       M
              IN BOARD                             C       M
              NFC BOARD                            M       M
              KEY BOARD                            M       M
              USB BOARD                            M       M
              LOADER                               M       M
              SUPPORT BOARD                     M     M
              Tips                  C -- Component Lever Repair
                                      M -- M d l L
                                           Module Lever R
                                                        Repair
                                                            i
                                                      2-1




                                     Title: Product Performance
Reference: WX-B-009-01                                                            Rev./Status: 0.1 / Draft
                                     Specification
Model : FX15 FX25 FX55                                                            Page 4 of 16

1. Introduction

  1.1    Purpose and Scope of Document
TheProduct Performance Specificationis the leading specification and is the response of development. Whenever the
specification cannot be met, Product Management is to be informed as early as possible in order to make sure the
marketing can respond in time.

This Product Performance Specificationdoes not cover software specifications. Software is described in
the URS documents and in the version matrix owned by Product Management. Product Management is
responsible for maintaining, distributing and updating the version matrix.

All changes to Product Performance Specificationhave to be submitted via Change Proposals. Changes
have to be marked in bold and/ or colours in the document for easy recognition in at least the update right
after the change. Deletion of text is done by strike through in order to make changes obvious in at least the
update after the change took place.

Note:
The Product Performance Specificationis a only a document to list out key-parameters / specification
points. It also describes product specific / unique parameters.For product performance, not mentioned
or specified in this document, such as: Electrical/ Mechanical / safety/Sound/ Quality Performance
/reliability requirement. Please refer to the PQR (Performance Quality Reliability) and product sound
specification.

This Product Performance Specificationdoes not cover software specifications. Software is described
in the URS documents and in the version matrix owned by Product Management. Product
Management is responsible for maintaining, distributing and updating the version matrix.

In case there are conflicting requirements between the Product Performance Specification (Set
specification) and the PQR document, then the Product Performance Specificationis the leading
requirement / dictates the valid parameters.
                                                   2-2




                                   Title: Product Performance
Reference: WX-B-009-01                                                      Rev./Status: 0.1 / Draft
                                   Specification
Model : FX15 FX25 FX55                                                      Page 5 of 16

2. General Information and Requirement

  2.1   Product Family Features
2.1.1   Identity and Key Features

FX15 FX25 FX55 is a MiniAudio Systemthat incorporates CD player with USB and Tuner FM/AM, and Blue
Tooth support.
Elements to include as generic requirements:
    1. Safety certification (cUL/FCC and CB/EMC/CE)
Following is a list of key features:
    1. BT module:BM830
    2. MCU: STM8S005C6T6 LQFP48
    3. CD disc /USB/MP3 MPEG (Sunplus SPH8104)
    4. FM/AM tuner Module:KST-MW004MV1-R78W2 IC : RN5B800
    5. Audio DSP:STA311B
    6. AMP:FX15STA518*2; FX25STA518*2; FX55STA516B*2
    7. Rated output power
        FX15180W - 30% (4 x 45W)
        FX25300W - 30% (4 x 75W)
        FX55600W - 30% (3 x 200W),200W x 2 + 200W

2.1.2   Styling, Forms and Functions

FX15 FX25FX55can be placed on a tabletop which should have a form factor and footprint that can be
                        nd
easily be located in a 2 room such as in thebedroom or small study room.
                       Features               Products          FX15 FX25FX55
                                           Stroke versions               All
                                                                Refer to MUS[3] for
                                     Design
                                                                      details
                                     Optical Drive Loading              Tray
                                     Tray Location                     below
                         Front       Tray Orientation             HORIZONTAL
                                     VFD                               UP
                                     Height of feet                   3mm
                       Dimension     Apparatus tray closed       mm (include rear
                                     W x D x H (mm)               connectors)
                         Weight      Main set                          kg
                                     speaker                           kg
                                     Color                            Black
                       Cosmetics
                                     Buttons                          Black
                                                2-3




                                  Title: Product Performance
Reference: WX-B-009-01                                                  Rev./Status: 0.1 / Draft
                                  Specification
Model : FX15 FX25 FX55                                                  Page 6 of 16



2.1.3 ACCESSORIES
Model                                                   FX15 FX25FX55
Stroke Version                 12
Region                         EU
Power Cord

Audio cable
                               NA
(3.5mm audio)
Tuner Antenna

Speaker cable

USB cable
                               NA
Remote Control
                             21keys
Battery
                              1xAAA




2.1.4     Controls, Local Display and LED Indications

Control keys on the set are:
   1. Standby-On
   2. Eject
   3. Play/Pause
   4. Next
   5. Pre
   6. FF
   7. FB
   8. Source (Disc, USB, FM, AM,Aux, BT)
   9. Stop
   10. Volume Knob

.
                                                    2-4




                                    Title: Product Performance
Reference: WX-B-009-01                                                        Rev./Status: 0.1 / Draft
                                    Specification
Model : FX15 FX25 FX55                                                        Page 7 of 16

  2.2   Mechanical General Information
The productappearances and functions are defined in their respective MUS. Product management
approves the MUS and it is a leading document where product appearance is applicable.

Please refer to Sh560 for mechanical information.




  2.3   Safety Standards
Where applicable:

/12, /05
