>> Download service documenatation <<Text preview - extract from the documentAV System LX7000SA/22S & LX8000SA/21R/22S/37S
Service LX7000SA
Service
Service
LX8000SA
For repair information on the SD4.00SA DVD Module, refer to Service
Manual "DVD Module SD-4.00SA_CH - 3122 785 12480 ".
Service Manual COMPACT
TABLE OF CONTENTS DIGITAL AUDIO
Page
Location of pc boards & Version variations ................ 1-2
Technical Specifications ............................................. 1-3
Measurement setup .................................................... 1-4
Service Aids, Safety Instruction, etc. .......................... 1-5
Disassembly Instructions & Service positions .............. 2
Service Test Programs .................................................. 3
Set Block diagram ...................................................... 4-1
Set Wiring diagram ..................................................... 5-1
Key & Control Boards .................................................... 6
ECO6 Tuner Board: System Non-Cenelec ................ 7A
System Cenelec ........................ 7B
Supply & Main Boards ................................................... 8
Power Amplifier Board ................................................... 9
AVC Board ................................................................... 10
P-Scan Board .............................................................. 11
Set Mechanical Exploded view & parts list ................. 12
CLASS 1
