Image preview - the first page of the document
>> Download MC55_SM_4588688698 documenatation <<
Text preview - extract from the document
Micro System MC-55/21M
TABLE OF CONTENTS
chapter chapter
Handling chip components and safety ............................. 1 - 1 VCD BOARD
Technical Specification & Service Tools .......................... 2 - 1 circuit diagram ....................................................... 9 - 1
Service Measurement .................................................. 2 - 2 layout diagram ....................................................... 9 - 1
Connections & Controls ................................................ 3 - 1
Instructions for use ................................................. 3 - 2 to 3 - 8 REMOTE CONTROL
circuit diagram ...................................................... 10 - 1
Block Diagram ........................................................4 - 1 to 4 - 2 layout diagram ...................................................... 10 - 1
Wiring Diagram ........................................................... 5 - 1
EXPLODED VIEW DIAGRAM
FRONT BOARD cabinet ................................................................. 11 - 1
circuit diagram ....................................................... 6 - 1 tape deck .............................................................11 - 2
layout diagram ....................................................... 6 - 2
Mechanical partslist ............................................... 11 - 1 to 11 - 2
MAIN BOARD Electrical partslist ............................................... 12 - 1 to 12 - 3
circuit diagram ........................................................7 - 1
layout diagram ........................................................7 - 2
POWER SUPPLY BOARD
circuit diagram ....................................................... 8 - 1
layout diagram ....................................................... 8 - 2
Safety regulations require that the set be restored to its original
condition and that parts which are identical with those specified
be used. CLASS 1
C
Copyright 1995 Philips Consumer Electroncis B.V. Eindhoven, The Netherlands LASER PRODUCT
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system or transmitted, in any form or by any means, electronic, mechanical, photocopying,
or otherwise without the prior permission of Philips.
Published by SS 0047 Service Audio Printed in The Netherlands Copyright reserved Subject to modification GB 3140 785 22600
PCS 104 676
1-1
HANDLING CHIP COMPONENTS
