Image preview - the first page of the document
>> Download MCD38812_ET-SB-EX-SI_1315980323 documenatation <<
Text preview - extract from the document
DVD Micro System MCD388
Recordable
ReWritable
TABLE OF CONTENTS
Location of PC Boards ............................................. 1-1 C024_TX-Transmit Board .......................................... 8
Electronic Specification ............................................. 1-2 Circuit diagram ............................................. 8-1 to 8-3
Measurement Setup ................................................ 1-3 Layout diagram ...................................................... 8-4
Service Aids............................................................... 1-4 C001SWF_RX-Receive Board .................................... 9
Instruction On CD Playability ........................... 1-5 to 1-6 Circuit diagram ............................................. 9-1 to 9-3
Software Version Check & Upgrade ........................ 2-1 Layout diagram ...................................................... 9-4
Malfuction Check Chart ............................................. 2-2 Power ...........................................................................10
Disassembly Diagram................................................ 3-1 Circuit diagram ................................................... 10-1
Block Diagram ......................................................... 4-1 Layout diagram ................................................... 10-2
Wiring Diagram ......................................................... 4-2 AMP Power Board ......................................................11
Display Board ............................................................... 5 Circuit diagram ....................................... 11-1 to 11-2
Circuit diagram ...................................................... 5-1 Layout diagram ................................................... 11-3
Layout diagram ...................................................... 5-2 Explode View ......................................................... 12-1
Small Board .................................................................. 6 Service Partlist .......................................... 13-1 to 13-2
Circuit diagram ...................................................... 6-1 Factory Partlist .......................................... 14-1 to 14-5
Layout diagram ...................................................... 6-1 Version list ............................................................. 15-1
Decoder Board ............................................................ 7
Circuit diagram ............................................. 7-1 to 7-7
Layout diagram ...................................................... 7-8
2009
DB 1004 3141 785 33791
Version 1.1
1-1
Location of PC Boards
Display Board Power Board DVD Decoder Board
Function Button Board C024-TX-Transmit Board
VERSION VARIATIONS :
Type /Versions: MCD388
Service policy /05 /12 /37 /55 /58 /61 /79 /93 /94 /96 /98
Board in used:
STANDBY BUTTON BOARD M M M M
DECODER BOARD M M M M
OPEN/CLOSE BUTTON BOARD M M M M
USB BOARD M M M M
DISPLAY BOARD C C C C
LAMP BOARD-1 M M M M
LAMP BOARD-2 M M M M
POWER BOARD M M M M
RADIO TRANSMIT BOARD M M M M
RADIO RECEIVE BOARD M M M M
AMP POWER BOARD M M M M
Type /Versions: MCD388
Features f
Feature difrence /05 /12 /37 /55 /58 /61 /79 /93 /94 /96 /98
RDS
VOLTAGE SELECTOR
ECO STANDBY - DARK
TDS
* TIPS : C -- Component Level Repair
.
M -- Module Level Repair
-- Used
1-2
Electronic Specification
AMPLIFIER SPEAKERS
