Image preview - the first page of the document
>> Download hfe_philips_mx980_service_en documenatation <<
Text preview - extract from the document
DIGITAL A/V SURROUND RECEIVER MX980/22S
FR984/00S
Service Manual DOLBY
D I G I T A L
For repair information please refer to Service Manual of FR965/00 & FR966/00S
(servicecode number = 3104 215 50070)
FR984/00S & MX980/22S is equal to FR966/00S except the following:
Miscellaneous:
3104 219 04460 REMOTE CONTROL
9965 000 11845 FRONT SPEAKER SILVER MX980FS
9965 000 11846 GRILL ASSY FRONT/REAR SPEAKER
9965 000 11847 CENTER SPEAKER SILVER MX980CS
9965 000 11848 GRILL ASSY CENTER SPEAKERK
9965 000 11849 REAR SPEAKER SILVER MX980RS
9965 000 11844 KEYHOLE BRACKET , MOUNTING
Electrical:
Led 6401,6421 are deleted
Led 6407,6408,6409,6410,6412,6413,6415,6416,6417,6418 red colour led
is changed into orange colour led code number : 4822 130 11589
uP 7415 changed into TMP87CS71F-MX970 code number : 3139 110 53181
Item 1301 changed into 1304 code number : 4822 265 11607
Item 2371 changed into 2317 4n7 code number : 5322 126 10223
Item 2372 changed into 2322 100p code number : 5322 122 32531
Item 2373 changed into 2328 4n7 code number : 5322 126 10223
Item 2374 changed into 2331 100p code number : 5322 122 32531
Item 2375 changed into 2335 4n7 code number : 5322 126 10223
Item 2376 changed into 2339 100p code number : 5322 122 32531
Mainstrafo 5001 changed code number : 3104 218 31020
Mains Outled 1053 are deleted
Copyright 2002 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system or transmitted, in any form or by any means, electronic, mechanical, photocopying,
or otherwise without the prior permission of Philips.
Published by MD 0205 Service Audio Printed in the Netherlands Subject to modification 3104 215 50190
1-1
Mechanical: the following items are changed into:
Item Code number Description
200 3104 217 53330 FRONT CABINET ASSY FR984
201 3141 017 74420 CAP END LEFT ASSY
202 3141 017 74430 CAP END RIGHT ASSY
203 3141 017 74440 BUTTON ASSY SURROUND
205 3141 017 74450 BUTTON ASSY TUNER
206 3141 017 74460 BUTTON ASSY MENU
207 3141 017 74600 BUTTON ASSY BASS
208 3141 017 74480 BUTTONS EASY LINK ASSY
209 3141 017 75200 RING SURROUND ASSY
210 3141 014 24200 LIGHT GUIDE VIRTUAL/HALL
211 3141 014 24210 LIGHT GUIDE SELECTOR
212 3141 014 24290 LENS IR
213 3141 017 74490 RING KNOB VOLUME ASSY
214 3141 017 74500 RING KNOB SOURCE SEL.
215 3141 017 74350 WINDOW DISPLAY ASSY
222 3141 017 74520 KNOB VOLUME ASSY
223 3141 017 74530 KNOB SOURCE SEL. ASSY
224 3141 017 74540 KNOB MENU NAV ASSY
228 3139 247 50570 LEG SILVER
230 3139 247 50560 LEG BLACK
282 4822 535 10638 POWER ROD
283 3141 017 74550 POWER CAP ASSY
2-1 2-1
EXPLODED VIEW
287
1004
Mains
8020
board
5001 284
236
Tuner
1001
282
1005
208 Front
283 Video S-VHS
Selector board
210
206 1006
203 1002
212 205
MDM module
201 Mono board
209
211 207 1003
214 230
215
228
223
226
224 202
200 FR995/FR996/FR985/FR986
222 213
