Image preview - the first page of the document
>> Download hfe_philips_mx999_service_en documenatation <<
Text preview - extract from the document
DIGITAL A/V SURROUND RECEIVER MX999/22S/37
FR994/00S/17
Service Manual
For repair information please refer to Service Manual of FR975/00/01C/17 & MX980D/37
(service code number = 3104 215 50060)
DOLBY
D I G I T A L
FR994/00S & MX999/22S is equal to FR975/00 except the following:
FR994/17 & MX999/37 is equal to FR975/17C except the following:
Miscellaneous
MX999/22S MX999/37
9965 000 11841 FRONT SPK SILVER MX999FS 9965 000 11856 FRONT SPK BLACK MX999FS
9965 000 11842 CENTER SPK SILVER MX999CS 9965 000 11857 CENTER SPK BLACK MX999CS
9965 000 11843 REAR SPK SILVER MX999RS 9965 000 11858 REAR SPK BLACK MX999RS
9965 000 11844 KEYHOLE BRACKET, MOUNTING 9965 000 11855 KEYHOLE BRACKET, MOUNTING
3104 219 04460 REMOTE CONTROL
3104 217 06780 MDM 2000 V2 module
Electrical:
Led 6401,6421 are deleted
Led 6407,6408,6409,6410,6412,6413,6415,6416,6417,6418 red colour led
is changed into orange colour led code number : 4822 130 11589
Item 7415 changed into TMP87CS71F - MX970 code number : 3139 110 53181
Item 1301 changed into 1304 code number : 4822 265 11607
Item 2371 changed into 2317 4n7 code number : 5322 126 10223
Item 2372 changed into 2322 100p code number : 5322 122 32531
Item 2373 changed into 2328 4n7 code number : 5322 126 10223
Item 2374 changed into 2331 100p code number : 5322 122 32531
Item 2375 changed into 2335 4n7 code number : 5322 126 10223
Item 2376 changed into 2339 100p code number : 5322 122 32531
Mainstrafo 5001for FR994/00S changed into code number : 3104 218 31030
Mainstrafo 5001for FR994/17changed into code number : 3104 218 31040
Mains Outled 1053 are deleted in FR994/00S
Mains Outled 1054 are deleted in FR994/17
Copyright 2002 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system or transmitted, in any form or by any means, electronic, mechanical, photocopying,
or otherwise without the prior permission of Philips.
Published by MD 0205 Service Audio Printed in the Netherlands Subject to modification 3104 215 50200
1-1
Mechanical: the following items are changed into:
Item Code number Description
200 3104 217 53350 FRONT ASSY FR994/00S
200 3104 217 53370 FRONT ASSY FR994/17
201 3141 017 74420 CAP END LEFT FR994/00S
201 3141 014 24480 CAP END LEFT FR994/17
202 3141 017 74430 CAP END RIGHT FR994/00S
202 3141 014 24490 CAP END RIGHT FR994/17
203 3141 017 74440 BUTTONS SURR. FR994/00S
203 3141 017 74280 BUTTONS SURR. FR994/17
205 3141 017 74450 BUTTONS TUNER FR994/00S
205 3141 017 74290 BUTTONS TUNER FR994/17
206 3141 017 74460 BUTTONS MENU FR994/00S
206 3141 017 74300 BUTTONS MENU FR994/17
207 3141 017 74600 BUTTONS BASS FR994/00S
207 3141 017 74580 BUTTONS BASS FR994/17
208 3141 017 74480 BUTTONS EASY LINK FR994/00S
208 3141 017 74320 BUTTONS EASY LINK FR994/17
209 3141 017 75200 RING SURR. FR994/00S
209 3141 014 24660 RING SURR. FR994/17
210 3141 014 24200 LIGHT GUIDE VIRTUAL/HALL
211 3141 014 24210 LIGHT GUIDE SELECTOR
212 3141 014 24290 LENS IR FR994/00S
212 3141 014 24650 LENS IR FR994/17
213 3141 017 74490 RING KNOB VOLUME FR994/00S
213 3141 014 24630 RING KNOB VOLUME FR994/17
214 3141 017 74500 RING KNOB SOURCE SEL.FR994/00S
214 3141 014 24640 RING KNOB SOURCE SEL. FR994/17
215 3141 017 74350 WINDOW DISPLAY ASSY FR994/00S
215 3141 017 74900 WINDOW DISPLAY ASSY FR994/17
222 3141 017 74520 KNOB VOLUME FR994/00S
222 3141 017 74360 KNOB VOLUME FR994/17
223 3141 017 74530 KNOB SOURCE SEL. FR994/00S
223 3141 017 74370 KNOB SOURCE SEL. FR994/17
224 3141 017 74540 KNOB MENU NAV FR994/00S
224 3141 017 74380 KNOB MENU NAV FR994/17
228 3139 247 50570 LEG SILVER
230 3139 247 50560 LEG BLACK
282 4822 535 10638 POWER ROD
283 3141 017 74550 POWER CAP FR994/00S
283 3141 017 74390 POWER CAP FR994/17
287 3104 211 29730 COVER PLATE SILVER FR994/00S
287 4822 442 01817 COVER PLATE BLACK FR994/17
2-1 2-1
EXPLODED VIEW
287
1004
Mains
8020
board
5001 284
236
Tuner
1001
282
1005
283 208 Front Video S-VHS
Selector board
210
206 1006
203 1002
212 205
MDM module
201 Mono board
209
211 207 1003
214 230
215
228
223
226
224 202
222 213
200 FR995/FR996/FR985/FR986
