Image preview - the first page of the document
>> Download philips_sm_5889 documenatation <<
Text preview - extract from the document
MANUAL 5889 DVD Player
Philips Consumer Electronics Company MANUAL 5889
A Division of Philips Electronics North America Corporation
Technical Service Data
Service Solutions Group Sec. 1A: Main Section
Technical Publications Dept. ( MDV443/17 )
P.O. Box 555, 401 E. Old Andrew Johnson Hwy.
Jefferson City,TN 37760
Supplement 1
Sec. 1B: Main Section
Magnavox
( MDV453/17 )
DVD PLAYER Operating Instructions
Schematic Diagrams
Cabinet & Electrical Parts Lists
Service Manual
MDV443/17, MDV453/17
MAGNAVOX
Model: MDV443/17
MAGNAVOX
Model: MDV453/17
DVD PLAYER
First Issue: 5/03
2003 Philips Consumer Electronics Company
Philips Consumer Electronics Company MANUAL 5889
A Division of Philips Electronics North America Corporation
Technical Service Data
Service Solutions Group
Technical Publications Dept. Supplement 1
P.O. Box 555, 401 E. Old Andrew Johnson Hwy. Sec. 1B: Main Section
Jefferson City,TN 37760
( MDV453/17 )
Operating Instructions
Schematic Diagrams
Cabinet & Electrical Parts Lists
DVD PLAYER
Service Manual
MAGNAVOX
Model: MDV453/17
DVD PLAYER
First Issue: 5/03
2003 Philips Consumer Electronics Company
IMPORTANT SAFETY NOTICE
Proper service and repair is important to the safe, reliable operation of all
Philips Consumer Electronics Company** Equipment. The service procedures
recommended by Philips and described in this service manual are effective
methods of performing service operations. Some of these service operations
require the use of tools specially designed for the purpose. The special tools
should be used when and as recommended.
It is important to note that this manual contains various CAUTIONS and
NOTICES which should be carefully read in order to minimize the risk of per-
sonal injury to service personnel. The possibility exists that improper service
methods may damage the equipment. It also is important to understand that
these CAUTIONS and NOTICES ARE NOT EXHAUSTIVE. Philips could not
possibly know, evaluate and advise the service trade of all conceivable ways
in which service might be done or of the possible hazardous consequences of
each way. Consequently, Philips has not undertaken any such broad evalua-
tion. Accordingly, a servicer who uses a service procedure or tool which is
not recommended by Philips must first satisfy himself thoroughly that neither
his safety nor the safe operation of the equipment will be jeopardized by the
service method selected.
** Hereafter throughout this manual, Philips Consumer Electronics Company
will be referred to as Philips.
WARNING
Critical components having special safety characteristics are identified
with a # by the Ref. No. in the parts list and enclosed within a broken
line* (where several critical components are grouped in one area) along
with the safety symbol # on the schematics or exploded views.
Use of substitute replacement parts which do not have the same specified
safety characteristics may create shock, fire, or other hazards.
Under no circumstances should the original design be modified or altered
without written permission from Philips. Philips assumes no liability,
express or implied, arising out of any unauthorized modification of
design. Servicer assumes all liability.
* Broken Line
TABLE OF CONTENTS
Note:
One model, MDV453/17, is covered by Supplement 1. This section only shows what differs between this model and
its base model covered by Section 1A.
OPERATING CONTROLS AND FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1-1
REMOTE CONTROL OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2-1
BLOCK DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3-1
System Control/ Servo Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3-1
Video/Audio Block Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3-3
SCHEMATIC DIAGRAMS / CBA'S AND TEST POINTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4-1
AV 2/3 Schematic Diagram Parts Location Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4-2
AV 2/3 Schematic Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4-3
DVD Main 2/3 Schematic Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4-5
IC101 Voltage Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4-7
DVD Main 3/3 Schematic Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4-9
WAVEFORMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5-1
WIRING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6-1
MECHANICAL PARTS LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7-1
ELECTRICAL PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8-1
Manufactured under license from Dolby Laboratories. "Dolby"
and the double-D symbol are trademarks of Dolby Laboratories.
OPERATING CONTROLS AND FUNCTIONS
1-1-1 E5775IB
1-1-2 E5775IB
REMOTE CONTROL OPERATION
1-2-1 E5775IBR
1-2-2 E5775IBR
BLOCK DIAGRAMS
System Control/Servo Block Diagram
NOTE FOR WIRE CONNECTORS:
" " = SMD 1. PREFIX SYMBOL "CN" MEANS CONNECTOR.
(CAN DISCONNECT AND RECONNECT.)
2. PREFIX SYMBOL "CL" MEANS WIRE-SOLDER
HOLES OF THE PCB.
(WIRE IS SOLDERED DIRECTLY.)
FOCUS SERVO SIGNAL TRACKING SERVO SIGNAL SLED SERVO SIGNAL SPINDLE SERVO SIGNAL
IC101
(MICRO CONTROLLER)
172 EXT CLOCK
92 CLK33M
170 BE CLOCK
IC451
(CLOCK GENERATOR)
X451
MULTI X'TAL 7 36.864MHz
3 1/4 PLL OSC 8 OSC
15 1/4 PLL2
10
14 17 FSEL
PCM-SCLK
A-MUTE
95 A-MUTE
FROM/TO ADAC-MD
VIDEO/ AUDIO 51 ADAC-MD
ADAC-MC
BLOCK DIAGRAM 50 ADAC-MC
ADAC-ML
96 ADAC-ML
I/P-SW
84 I/P-SW IC2001
(FRONT PANEL CONTROL) FL2001
IC301
(SERVO DRIVE) 1G 23
GRID FIP
~
~
FS(+) 27 7G 17
15 FOCUS +
FS(-) ACTUATOR + - 26 152 FOCUS DRIVE
TO DIGITAL SIGNAL 16 DRIVE -
PROCESS BLOCK TS(+) 25 a/KEY-1 7
DIAGRAM TS(-) 24 b/KEY-2 8
c/KEY-3 9
TRACKING + d/KEY-4 10 SEGMENT
14 + -
ACTUATOR
- 1 150 TRACKING CN401 CN1001 e 11
13 DRIVE DRIVE
2 FP-STB 59 16 FP-STB 16 2 FP-STB f 12
TRAY-OUT 3 FP-DIN 54 18 FP-DIN 18 28 FP-DIN g 13
FP-DOUT 55 20 FP-DOUT 20 27 FP-DOUT h 14
12 SPINDLE FP-CLK 53 21 FP-CLK 21 1 FP-CLK i 16 JP2001 JP2002
MOTOR + 4 71 SPDL REMOTE
11 DRIVE - + 61 22 REMOTE 22 7 KEY-1 7
- 5
TRAY-IN 2 KEY-2 2
6 6 KEY-3 6 KEY
SPINDLE 5 KEY-4 5 MATRIX
MOTOR 17 SLED K2 4 1 K2 1
CN301 MOTOR +
18 DRIVE - 23 70 SLD K1 3 8 K1 8
M SP(+) 3
SP(-) 4 RM2001
TRAY-OUT 5 +3.3V REMOTE
SLED IC461
TRAY-IN 6 SENSOR
MOTOR
GND 7
5 RESET 4 68 RESET
M SL(-) 8
SL(+) 9
FG-IN 1 IC202
(OP AMP) 97 TRAY-OUT
FG CBA 60 TRAY-IN
12 14 66 FG-IN
FG
SENSOR
DVD MAIN CBA UNIT AV CBA FUNCTION CBA
DRIVE CBA
1-3-1 1-3-2 E5775BLS
Video / Audio Block Diagram
VIDEO SIGNAL DATA(AUDIO) SIGNAL AUDIO SIGNAL
NOTE FOR WIRE CONNECTORS:
1. PREFIX SYMBOL "CN" MEANS CONNECTOR.
(CAN DISCONNECT AND RECONNECT.)
" " = SMD 2. PREFIX SYMBOL "CL" MEANS WIRE-SOLDER
HOLES OF THE PCB.
(WIRE IS SOLDERED DIRECTLY.) WF1 IC1402 (VIDEO DRIVER)
4dB 2dB Y C
6 AMP LPF AMP DRIVER 18 3 4 JK1401
WF3 S-VIDEO OUT
2dB 1 2
WF2 AMP DRIVER 21
CN601 CN1601 4dB 2dB
VIDEO-Y 2 AMP LPF AMP DRIVER 23
7 VIDEO-Y 7
FROM DIGITAL VIDEO-C
SIGNAL PROCESS 9 VIDEO-C 9 JK1404
VIDEO-Cb 4dB 2dB
BLOCK DIAGRAM 5 VIDEO-Cb 5 9 AMP LPF AMP DRIVER 15 COMPOSITE
VIDEO-Cr
3 VIDEO-Cr 3 VIDEO OUT
4dB 2dB
11 AMP LPF AMP DRIVER 13 VIDEO-Y
OUT
MUTE VIDEO-Cb
OUT
3
VIDEO-Cr
OUT
SW1401
PROGRESSIVE
/INTERLACE
IC601 (AUDIO DAC)
FROM SPDIF JK1202
DIGITAL 4X/8X L-CH Q1351
PCM-BCK DAC LPF+AMP 7
SIGNAL 1 OVERSAMPLING ENHANCED AMP DIGITAL
PROCESS PCM-DATA0 SERIAL DIGITAL FILTER MULTI-LEVEL
2 PORT AUDIO OUT
BLOCK PCM-LRCLK /FUNCTION DELTA-SIGMA
DIAGRAM 3 CONTROLLER MODULATOR R-CH CN601 CN1601 WF6 IC1201 (AMP)
DAC LPF+AMP 8
1 I/P-SW 1 WF4
JK1404
18 SPDIF 18 3
1 AUDIO-L
13 AUDIO-L 13 2
OUT
15 AUDIO-R 15
I/P-SW 12 14 A-L-MUTE 14
ZERO DETECT 6
ADAC-MD 11 16 A-R-MUTE 16 WF5 7 AUDIO-R
13 5
ADAC-MC 12 A-MUTE 12 OUT
14 SERIAL
ADAC-ML CONTROL
15
FROM/TO
SYSTEM SYSTEM CLOCK +5V
CONTROL
/SERVO
BLOCK Q1202
DIAGRAM
16 Q1204
PCM-SCLK Q1201
A-MUTE +3.3V Q1203
AV CBA
DVD MAIN CBA UNIT +3.3V
1-3-3 1-3-4 E5775BLV
SCHEMATIC DIAGRAMS / CBA'S AND TEST POINTS
Standard Notes Notes:
WARNING 1. Do not use the part number shown on these draw-
ings for ordering. The correct part number is shown
Critical components having special safety characteris- in the parts list, and may be slightly different or
tics are identified with a # by the Ref. No. in the parts amended since these drawings were prepared.
list and enclosed within a broken line* (where several
2. To maintain original function and reliability of
critical components are grouped in one area) along
repaired units, use only original replacement parts
with the safety symbol # on the schematics or
which are listed with their part numbers in the parts
exploded views.
list section of the service manual.
Use of substitute replacement parts which do not have
the same specified safety characteristics may create 3. Prefix symbol "CN" means "connector" (can dis-
shock, fire or other hazards. connect and reconnect).
Under no circumstances should the original design be Prefix symbol "W" means "wire-solder holes of the
modified or altered without written permission from PCB" (wire is soldered directly).
Philips Consumer Electronics Company. Philips 4. How to read converged lines.
assumes no liability, express or implied, arising out of
any unauthorized modification of design. Servicer 1-D3 3 1-B1
assumes all liability. AREA D3
Distinction Area
2 AREA B1
* Broken Line : Line Number
(1 to 3 digits) 1 1-D3
Capacitor Temperature Markings
A B C D
Capacity Standard Temperature
Mark Examples:
