Image preview - the first page of the document
>> Download HB400_SM_4566948647 documenatation <<Text preview - extract from the document HPA Solarium
HB 400/A
Service HB 404/A
Service
Service
Service PHILIPS ORIGINA
L HOME SOLARIA
MIN 0 5
10
60
15
cm
55
20
50
25
45
30
40 35
Domestic Appliances and Personal Care
Service Manual
General TECHNICAL DATA
Owing to its compactness the HB 400/A and HB 404/A Input voltage : 230 V
are only suitable for tanning part of the body - the face Input power : 440 W
in most cases. UVA-source (LA1) : 1 x HPA flexpower 400-600
By increasing the curing distance the area can be Starter (S1) : 1 x SN 58-spec.
somewhat enlarged. Ballast (L1) : 1 x BHA 400L
However, this is at the expense of the curing time Timer : 60 mins Diehl
(see directions for use). Radiation area : 60 x 40 (at 50 cm)
Protection goggles : HB071 - 4822 690 80123
Output UVX 36 meter : Min. 4.2 mW/cm2
TCO
SK2 LA1
..................
N M La1 M
TCO
S1 L1
SK2
BLACK
1 2 BLACK
S1 RED N L
BLUE
1 SK1 2
BROWN
RED
L L1
BLACK
SK1 BROWN
