Image preview - the first page of the document
>> Download 43PFT6100S documenatation <<Text preview - extract from the documentColour Television Chassis
43PFT6100S/56
55PFT6100S/56
Product Specification Sheet (Page1-23)
User Manuel Part(Page24-41)
Troubleshooting Procedure(Page42-47)
Factory Mode Adjustment (Page48-50)
Software Upgrades(After Service)(Page51-61)
Main Board Circuit Diagram (Page62-69)
Power Board Circuit Diagram (Page70)
Product Specification Sheet
43" FHD STV(43S91F-DVB) 55" FHD STV(55S91F-DVB)
Series name 43PFT6100 55PFT6100
Set Product Manager
Set Product Manager in
outsourcing company
E-mail address of main
contact in outsourcing
company
Set Project Manager
Status
CR (yyyyww) of leading
set
Platform/Chipset T8E3-6A628 DVB-T2 T8E3-6A628 DVB-T2
Processor type (CPU) /
GPU
Picture/Display
1
RC
Backlight Type (Panel
DLED DLED
Supplier)
Diagonal Screen Size 42.51" 54.64"
Perfect Motion Rate
Picture Performance PMR 200 HZ PMR 200 HZ
Index
Panel Frequency (Native) 60HZ 60HZ
Chasis Frequency 60HZ 60HZ
Backlight Dimming PWM PWM
Scanning Segments
48.25--863.25MHZ 48.25--863.25MHZ
(amount)
Panel Resolution 1920*1080 1920*1080
Aspect ratio 16:9 16:9
Brightness (Home Vivid
Min220cd/m2 Typ:260cd/m2 Min:300cd/m2Typ:350cd/m2
Mode) cd/m
