Image preview - the first page of the document
43PFH5800


>> Download 43PFH5800 documenatation <<

Text preview - extract from the document
Colour Television                  Chassis




                    43PFH5800/96

                    49PFH5800/96

                    55PFH5800/96





Product Specification Sheet

                                                 43S91F-DVB FHD Smart TV     49S91F-DVB FHD Smart TV



Series name                                           43PFH5800/96                49PFH5800/96


Platform/Chipset                                       T8E5-6A628                  T8E5-6A628


Processor type (CPU) / GPU




Picture/Display




Backlight Type (Panel Supplier)                            DLED                      DLED
Diagonal Screen Size                                      42.51"                     48.5"
Perfect Motion Rate                                  1920*1080@60Hz             1920*1080@60Hz
Panel Frequency (Native)                                   60HZ                      60HZ
Chasis Frequency                                           60HZ                      60HZ
Backlight Dimming                                         PWM                        PWM
                                                      AIR:CH2-CH69                 AIR:CH2-CH69
Scanning Segments (amount)                          CABLE:CH1-CH135              CABLE:CH1-CH135
                                                    DVB-T:470-806MHZ            DVB-T:470-806MHZ
Panel Resolution                                        1920*1080                   1920*1080
Aspect ratio                                              16:09                       16:09
Brightness (Home Vivid Mode) cd/m
