Image preview - the first page of the document
55PFF5055


>> Download 55PFF5055 documenatation <<

Text preview - extract from the document
          55PFF5055/T3
Philips
                        Description                                 55PFF5055/T3          55" FHD DLED TV (55S71F)
                             Size and backlight                     55" DLED
                             Resolution                             FHD 1920x1080, Widescreen 16:9 Aspect Ratio
                             Refresh Rate                           60Hz
                             Brightness                             300 cd/m2300~350
         Panel
                             Dynamic Contrast Ratio                 1200:1
                             Response Time                          8ms
                                                                    Horizontal: 176 Degrees
                             Viewing Angle
                                                                    Vertical: 176 Degrees
                             ATV System                             NTSC+PAL
                             DTV System                             DTMB
                             Sound system                           ID/KB/G M
     TV System               Nicam                                  N/A
                             Teletext                               N/A
                             Digital Amplifier                      N/A
                             Android System                         Android 4.4
                             Composite + L/R Auido                  2
                             Component + L/R Audio                  1
    Signal Input             HDMI                                   3
                             USB                                    3
                             PC Input                               Analog RGB (Dsub)
                             Buit-in Speakers                       8 Watts Total*2
                             Headphone Output                       1
   Audio Output
                             Line Output                            1*Video-out
                             Digital Audio Output (S/PDIF) 1
                             Input range                            Universal 100~240 VAC 50/60Hz
                             Ambient Temperature                    5 to 40 deg C
        Power                Consumption                            130Watts ( Max. )
                             Standby power consumption 0.5W
                             Energy Efficiency Class                2

                             Languages                              Chinese(default,English Multi-languages

  OSD Function               Picture Mode                           Vivid,Standard,Soft,Personal
                             Sound Mode                             Standard,Music,Cinema,Personal
                             Sleep Timer                            Off ,10 to 180 Min (10 min per adjust)
                             Chipset                                MSD6A628-T8D1
                                                                    3D Comb Filter, 3D Color Management, Cross
                             Picture Enhancement                    Color Reduction,MPEG Noise Reduction,
                                                                    Montion Adaptive De-interlacer
                             Video playback                         PAL,SECAM
                             Music Support                          MP3M4AAAC
                             Picture Support                        JPEGBMPPNG

                                                                    Containers AVI, MKV, MPEG-1, MPEG-2,
       Features                                                     MPEG-4,Motion JPEG, MPEG2_HD
                             Video support                          MPEG4_SD, MPEG4_HD, H.264
                                                                    dat mpg mpeg1/2H.264H.265vob
                                                                    mkvdivaviasf
                             Screen adjustment format               Wide screen, 4:3, Movie 16:9,Subtitle Zoom
                                                                    Treble
                                                                    Bass
                             Sound Enhancement
                                                                    AVL
                                                                    Virtual Surround
                             Computer inputs                        up to 1920
