Image preview - the first page of the document
55PFT6110 56


>> Download 55PFT6110 56 documenatation <<

Text preview - extract from the document
Colour Television                     Chassis




                    49PFT6100/56
                    55PFT6100/56
                    55PFT6110/56





Product Specification Sheet
                                                49" FHD SMART DTV(49S91F-DVB)    55" FHD SMART DTV(55S91F-DVB)
                                                          49PFT6100                        55PFT6100
Series N/Ame
                                                          49PFT6110                        55PFT6110
Platform/Chipset                                  T8E3-MSD6A628VXEM DVB-T2         T8E3-MSD6A628VXEM DVB-T2
Processor type (CPU) / GPU




Picture/Display




RC                                                  7601-32E232-0344FLP1             7601-32E232-0344FLP1
Backlight Type (Panel Supplier)                             DLED                             DLED
DiagoN/Al Screen Size                                       48.5"                           54.64"
Perfect Motion Rate
                                                             200 PMR                       200 PMR
Picture Performance Index
Panel Frequency (N/Ative)                                     60HZ                              60HZ
Chasis Frequency                                              60HZ                              60HZ
Backlight Dimming                                             PWM                               PWM
Scanning Segments (amount)                             48.25--863.25MHZ                 48.25--863.25MHZ
Panel Resolution                                           1920*1080                        1920*1080
Aspect ratio                                                  16:9                              16:9
Brightness (Home Vivid Mode) cd/m
