Image preview - the first page of the document
32pfh5509_88_fhi_eng


>> Download 32pfh5509_88_fhi_eng documenatation <<

Text preview - extract from the document
Software History

NOTE: Each release contains all solutions identified in the earlier version.
The latest software solves the issues below:

TPN141E_010.003.076.128 (Date published: 2016-10-27)
    Improvement on channel update message [Russia]
    Improvement on HbbTV stability
    Improvement on VoD Maxdome
    Translation issue [Russia]
    Clock improvement in SMTV
    Improvement in HUE setup
    Improvement in PVR recording [France]

TPN141E_010.003.070.128 (Date published: 2016-05-30)
    To support Hue 2.0 bridge
    Pairing improvements for AL+Hue light bulbs
    AL+Hue support for Wave your flag app

TPN141E_010.003.068.128 (Date published: 2016-04-21)
    Improvement in [Skype]
    Improvement in browsing HBBTV
    New homing frequency for YouSee (Denmark)
    Update in channel lists (Swiss)
    Improvement in HUE bridge pairing

TPN141E_010.003.066.128 (Date published: 2016-03-17)
 Improvement in [Spotify]
 Improvement in PLAY-READY video playback
 Improves PVR functionality when in DVB-C / DVB-S
 Improves recording functionality in IP-EPG
 Improves lip-sync when in DVB-C
 Improves RC response
 Stability improvement for channel zapping, country Russia
 Improves on subtitles activation timing
 Improves 3D when in APPS MEGOGO
 Improvement in [MyRemote] App when in WiFi
 TV hang up when combination usage of cards + CAM, country Italy
 Update in Channel list (Swiss) - TV5MONDE EUROPA, TV5MONDE, EuroNews
 Removal of black rectangle bar on DVB-T
 Correction of translation error (Slovakia)
 Correction of translation error (Poland)
 Skype resets the picture format always to 'Wide screen'
TPN141E_010.003.062.128 (Date published: 2015-12-07)
 To add Wide screen picture format
 Solution for UK BBC Red Button service
 Improvement on VoD Megogo Russia
 Improvement on DVB-T update messaging

TPN141E_010.003.054.128 (Date published: 2015-10-05)
 Improvements when ending recordings
 Improvement Ambilight lounge mode
 Corrected picture format 21:9 video playback
 Improvement last status main power on
 Improvement Pin protected recordings in standby

TPN141E_010.003.050.128 (Date published: 2015-08-24)
 Updated predefined channel list Switzerland and Turkey
 Improvement for recordings when broadcast program guide is used

TPN141E_010.003.046.128 (Date published: 2015-05-29)
 TV is not able to which on via remote control from standby-provider Orion Telecom
 TV Hangs up when reorder channel list
 Philips channel list edit shows error message "No channel list found"
 Not able to copy channel list
 [Bulgarian]Translation error
 Incorrect time zone when setting country dependent clock
 Incorrect time zone after reinstalling channels
 Skype feature improvement
 [DVB-S: Swiss] Predefined channel list
 [Poland] DVB-T channels cause TV reboot
 Channel bar running when pressing P+
 After every restart shows message "the network data changed. Do you want to perform update?"

TPN141E_010.003.038.128 (Date published: 2015-03-25)
 TV cannot find satellite.
 3D picture abnormity.
 HbbTV blue key shows error message and cannot playback the video.
 3D effect delay in USB/HDMI mode.
 Ambilight+Hue bulbs can't be controlled during phone "Philips Ambilight TV" connects to TV.
 Ambilight lounge mode behavior is incorrect.
 When play 3D video, RC react un-smoothly.
 Error message: "connect fail" popping up when network connecting successfully.
 Channel change abnormally.
 Ambilight+Hue bulbs show error color when connecting to PC.
 The bulbs changes speed no difference after adjust Immersion.
   TV lost channel logo when copy channel from USB.
   Slow reaction on RC commands.
   TV reboots whilst watching videos in Netflix.
   Error message: `Network data changed, update now' is displayed.

TPN141E_010.003.030.128 (Date published: 2015-01-19)
 Audio-Video sync up issue while playing the WMV files.
 Smart TV hangs with Dutch VOD (Uitzending Gemist).
 [Slovenia ] Text overlapping /translation/missing.
 Hang up when change channel list.
 FastScan problems with the Skylink in Slovakia and Czech Republic.
 Error message "No Single" invoking Broadcast EPG.
 Incorrect Network information.

TPN141E_010.003.026.128 (Date published: 2014-12-01)
 Fixed issue: Miracast function.
 Fixed issue: HbbTV "ANT. Galiobrowser" error message.
 Fixed issue: When used QUANTIS Cam, USB is no content.
 No internet, RC Red and digit key do not work in HBB TV channel.
 Fixed issue: Set could not enter HbbTV after pressing OK key.

TPN141E_010.003.020.128 (Date published: 2014-10-16)
 Fixed issue: Channel clone.
 Fixed issue: Static IP not workable.
 Fixed issue: TV doesn't react on some RC commands. (Ex: Home menu, EPG menu and Channel list)
 Fixed issue: Ambilight setting are not saved after switching the TV.
 Fixed issue: Ambilight settings are not saved after turning off the TV.
 Fixed issue: Ambilight not stopping immediately after shutdown the TV.

TPN141E_010.003.010.128 (Date published: 2014-09-01)
 Skype update.
 Fixed issue: Timeshift issue in HbbTV.
 Fixed issue: HDMI Audio issue with Humax STB.
 Fixed issue: VOD content not working.
 Fixed issue: Ambilight + Hue.
 Fixed issue: Miracast not functioning
 Fixed issue: Once P+ is pressed the channel bar continues to run.

TPN141E_010.003.006.128 (Date published: 2014-08-04)
 Fixed issue: [France] M6 info banner not disappear.
 Fixed issue: HbbTV "ANT. Galiobrowser" error message.
 Fixed issue: [Denmark, Finland]: HbbTV is not working on DR channels.
 Fixed issue: OSD message "no program available" sporadically when channel selected.

TPN141E_010.003.002.128 (Date published: 2014-07-02)
 Change the source from the UHD source to another source, the source name become bigger.
    In the EPG, the high light bar is always grey.
    Fixed issue: [Ukraine] Translation correction and text formatting on Skype correction.
    Fixed issue: [Ukraine] VOD playback problem in Megogo & Oll TV.
    Fixed issue: Upoint is not available in USB browser.
    Fixed issue: Pointer not disappear when press arrow key in Smart TV.
    Fixed issue: After RC off about 15-20min, set can't switch to ATV from DTV in favorites list.
    Fixed issue: App Phonestat - all audio clips with distorted sound.
    Fixed issue: Unable to change channel in EPG.

TPN141E_010.002.038.128 (Date published: 2014-06-13)
 Fixed issue: HbbTV video does not start.

TPN141E_010.002.036.128 (Date published: 2014-05-26)
 BBC iPlayer picture format issue.
 App Phonestar - all audio clips with distorted sound.
 HDMI ARC issue / OSD message permanently shown up.
 After channel installation OSD shows "no signal" and no picture.
 Hue lamps and ambi-light cannot switch to static color.
 Error message when copy channel list.
 [UK] missing analogue channels.
 MPEG Artifact reduction not work
 Feature release: Wireless subwoofer for 7500 series.
 Iphone "My Remote Apps" -> "Wi-Fi smart screen" can't put TV or can't turn off TV
 Remote Control Pointer not work
 3D effect not working
 TV hang up after it is paired with the ambi-light bridge to control the hue bulbs for few hours
 TV shows black bars seen on left and right side of the screen when user toggles the 3D effect selection
   from 2D to 3D
 TV guide(EPG) model, TV can't switch the channels
 channel lock not working when joystick (the mechanical switch on the back or bottom of the TV set) is
   used for channel zapping
 TV reboot when access "My Remote Apps -> Wi-Fi Smart Screen" function in Android devices.
 Cannot active HbbTV on DVB-C or DVB-S.

TPN141E_010.002.016.128 (Date published: 2014-03-25)
 H and T model show satellite icon in channel list.
 MyRemote control and smart screen function NG.
    Race conditions hang up issue.

TPN141E_010.002.013.128 (Date published: 2014-03-11)
 Enter YouTube will be black screen.
 HDMI side source name display as "HDMI3".
 TV would freeze in loading by entering to USB.
 In Smart TV play video, TV shows "Ambilight" list but can't adjust it.
 Picture abnormal during press RC MULTIVIEW key in Smart TV.
 TV can't enter some APP during CI+ 1.3 insert.
   When at other source do re-install TV and finish install channel, return to TV source by source list, TV
   shows no signal.

TPN141E_010.002.009.128 (Date published: 2014-02-27)
 Multi language translates error or no translates.
 [Hbbtv] Picture is abnormal.
 Picture is black in USB mode.
 In ATV channel and some DTV channel, TV always show Redio channel.
 Picture format stretch, when adjust to the max, screen abnormal.
 DLNA DMP can't play any music/video/photo.

TPN141E_010.002.006.128 (Date published: 2014-02-12)
 Initial production software.
