Image preview - the first page of the document
>> Download 40PFL6626H12_SB-EX-SI_1321251161 documenatation <<
Text preview - extract from the document
Colour Television Chassis
Q552.2E
LA
19100_000_110214.eps
110929
Contents Page Contents Page
1. Revision List 2 B09 393912364955 192
2. Technical Specs, Diversity, and Connections 2 313912364955 SSB Layout 193
3. Precautions, Notes, and Abbreviation List 11 B01 313912365192 195
4. Mechanical Instructions 15 B02 313912365192 206
5. Service Modes, Error Codes, and Fault Finding 44 B03 313912365192 215
6. Alignments 64 B04 313912365192 223
7. Circuit Descriptions 73 B05 313912365192 228
8. IC Data Sheets 79 B06 313912365192 229
9. Block Diagrams B07 313912365192 233
Wiring diagram Berlinale 32" 93 B08 313912365192 234
Wiring diagram Berlinale 40" - 46" 93 B09 313912365192 236
Wiring diagram Blockbuster 37" 96 B10 313912365192 237
Wiring diagram Blockbuster 40" - 55" 97 313912365192 SSB Layout 238
Wiring diagram Sundance 32" - 37" 100 E 27221719026x IR/LED/Key Board 287
Wiring diagram Sundance 42" - 47" - 55" 101 E 27221719027x IR/LED/Key Board 288
Block Diagram Video 102 E 27221719028x IR/LED/Key Board 289
Block Diagram Audio 103 E 27221719029x IR/LED/Key Board 291
Block Diagram Control & Clock Signals 104 AL1 820400091254 296
Block Diagram I2C 105 AL3 820400091232 302
Supply Lines Overview 106 AL 310431364752 AmbiLight Layout 315
10. Circuit Diagrams and PWB Layouts Drawing AL 310431364762 AmbiLight Layout 316
B01 313912364954 107 AL 310431364792 AmbiLight Layout 317
B02 313912364954 118 AL 310431364803 AmbiLight Layout 318
B03 313912364954 127 AL 310431364812 AmbiLight Layout 319
B04 313912364954 135 AL 310431365671 AmbiLight Layout 320
B05 313912364954 140 TS1 313912365252 321
B06 313912364954 141 11. Styling Sheets
B07 313912364954 145 Berlinale 32" 322
B08 313912364954 146 Berlinale 40" & 46" 323
B09 313912364954 148 Blockbuster 32" 324
313912364954 SSB Layout 149 Blockbuster 37" 325
B01 393912364955 151 Blockbuster 40" & 46" 326
B02 393912364955 162 Blockbuster 55" 327
B03 393912364955 171 Infinity 32" 328
B04 393912364955 135 Infinity 42" 329
B05 393912364955 184 Sundance 32" & 37" 330
B06 393912364955 185 Sundance 42", 47" & 55" 331
B07 393912364955 189
B08 393912364955 190
