Image preview - the first page of the document
>> Download lc46e_aa_miravision_range_supplement_154 documenatation <<
Text preview - extract from the document
Colour Television Chassis
LC4.6E
AA
Miravision Range
Supplement to manual LC4.6E (3122 785 14710)
F_15701_000.eps
140406
Contents Page
1. Technical Specifications, Connections, and Chassis
Overview 2
2. Safety Instructions, Warnings, and Notes 3
3. Directions for Use 5
4. Mechanical Instructions 6
5. Service Modes, Error Codes, and Fault Finding 10
6. Block Diagrams, Test Point Overviews, and
Waveforms 10
7. Circuit Diagrams and PWB Layouts 10
8. Alignments 10
9. Circuit Descriptions, List of Abbreviations, and IC
Data Sheets 10
10. Spare Parts List 11
11. Revision List 12
