Image preview - the first page of the document



>> Download TPM17.1E eu documenatation <<

Text preview - extract from the document

                                                                                                                              TPM17.1E
                                                                                                                                   EU




                              Chassis name                                           Platform                  Model name
                                                                                                               43PUS6412/12
                                                                                                               49PUS6412/12
                                                                                                               55PUS6412/12
                                                                                                               65PUS6412/12
                                                                                                               49PUS6482/12
                                                                                                               55PUS6482/12
                                  TPM17.1E LA                                MTK5596+333/334
                                                                                                               49PUS7002/62
                                                                                                               55PUS7002/62
                                                                                                               49PUS7502/12
                                                                                                               55PUS7502/12
                                                                                                               65PUS7502/12
                                                                                                               55POS9002/12




Published by YMC/SC 1734 Quality                                                    Subject to modification                       3122 785 20321
                                                                                                                                    2017-Aug-25
