Image preview - the first page of the document
>> Download Philips 190g6 documenatation <<
Text preview - extract from the document
19 inch SXGA TFT LCD Monitor/TV Chassis: Hudson6
Service
Service
Service 190G6FB/00
190G6FB/93
190G6FB/96
190G6FB/97
Horizontal frequencies
30 - 83 kHz
TABLE OF CONTENTS
Description Page Description Page
Important Safety Notice---- ------------------------------ 2 Scaler Diagram&C.B.A. ---------------------------37~49
Technical Data----------------------------------------------3 Inverter Diagram&C.B.A.--------------------------50~51
Instalation&On Screen Display ----------------------4~9 Audio Diagram&C.B.A. ----------------------------52~56
Aging,Factory mode--------------------------------------10 Power Diagram&C.B.A. ---------------------------57~60
Mechanical Instructions ----------------------------11~12 HD Diagram&C.B.A. -------------------------------61~63
Color adjustment -----------------------------------------13 LED Diagram&C.B.A.------------------------------64~66
Warning Message ----------------------------------------14 Control Diagram&C.B.A. --------------------------67~69
Troubleshooting ------------------------------------------15 Exploded View -------------------------------------------70
Electrical instruction --------------------------------16~19 Spare& Recommended parts list-----------------71~75
DDC Instructions-------------------------------------20~26 General product specification--------------------76~94
DDC DATA --------------------------------------------27~28 Repair tips--------------------------------------------95~96
Philips Pixel Defect Policy ------------------------------29 Repair Flow chart-----------------------------------97~98
Update UAC3556 FW ------------------------------------30 Failure mode of panel-----------------------------------99
ISP Instructions --------------------------------------31~32 Safety Test Requirments -----------------------------100
Wiring&Block Diagram------------------------------33~36 Different parts list--------------------------------------101
Update for 190G6--------------------------------------102
SAFETY NOTICE
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFORMER FOR THIS UNIT WHEN SERVICING.
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
Published by BCU Monitors Printed in Suzhou Copyright reserved Subject to modification K Sep. 16 2005 GB 3138 106 10484
2 190G6 LCD/TV Important Safety Notice
Go to cover page
Proper service and repair is important to the safe,
reliable operation of all Philips Consumer Electronics
Company** Equipment. The service procedures
recommended by Philips and described in this service
manual are effective methods of performing service
operations. Some of these service operations require
the use of tools specially designed for the purpose. The
special tools should be used when and as
recommended.
It is important to note that this manual contains various
CAUTIONS and NOTICES which should be carefully
read in order to minimize the risk of personal injury to
service personnel. The possibility exists that improper
service methods may damage the equipment. It is also
important to understand that these CAUTIONS and
NOTICES ARE NOT EXHAUSTIVE. Philips could not
possibly know, evaluate and advise the service trade of
all conceivable ways in which service might be done or
of the possible hazardous consequences of each way.
Consequently, Philips has not undertaken any such
broad evaluation. Accordingly, a servicer who uses a Take care during handling the LCD module with
service procedure or tool which is not recommended by backlight unit
Philips must first satisfy himself thoroughly that neither
- Must mount the module using mounting holes
his safety nor the safe operation of the equipment will
arranged in four corners.
be jeopardized by the service method selected. - Do not press on the panel, edge of the frame
strongly or electric shock as this will result in damage
* * Hereafter throughout this manual, Philips Consumer
Electronics Company will be referred to as Philips. to the screen.
- Do not scratch or press on the panel with any sharp
objects, such as pencil or pen as this may result in
damage to the panel.
WARNING - Protect the module from the ESD as it may damage
the electronic circuit (C-MOS).
Critical components having special safety - Make certain that treatment person s body are
!
characteristics are identified with a by the Ref. No. grounded through wrist band.
in the parts list and enclosed within a broken line*
(where several critical components are grouped in one
area) along with the safety symbol ! on the
schematics or exploded views.
Use of substitute replacement parts which do not have
the same specified safety characteristics may create
shock, fire, or other hazards.
Under no circumstances should the original design be
modified or altered without written permission from
Philips. Philips assumes no liability, express or implied,
arising out of any unauthorized modification of design.
Servicer assumes all liability.
* Broken Line
Technical Data 190G6 LCD/TV 3
Go to cover page
LPL panel Input DVI-D connector pin
Type NR. : LM190E03_TLC1
Display area(mm) : 376.32(H) x 301.056(V) (19.0-inch
diagonal)
Number of Pixels : 1280(H) x 1024(V)
Pitch ( mm ) : 0.098(H) x 0.294(V)
Color pixel arrangement : RGB vertical stripes
Display operating mode : Transmissive mode, normally white Pin No. Description
Color depth : 16.2M colors ( 6 bits with FRC) 1 T.M.D.S. data2-
Brightness (cd/m^2) : 420(cd/m^2)(Center 1 points Typ.)
2 T.M.D.S. data2+
Viewing angle(CR>10) : 88 O (R/L), 85 O(Up) , 85 O (Down), Typ
Surface treatment : Hard coating(2H) & Low reflection 3 T.M.D.S. data2 shield
glare treatment of front polarizer 4 No Connect
Electrical interface : LVDS (2 port) 5 No Connect
Response Time : 8ms(typ.) (Tr+Tf) 6 DDC clock
Power Consumption(W) : 3.05(Max) for LCD, 22.53(Max) for
7 DDC data
inverter
Contrast ratio : Typical 700 : 1 8 No Connect
Module size (mm) : 396.0(W) x 324.0(H) x 16.5(D) 9 T.M.D.S. data1-
Module weight (g) : 2700(Typ), 2840(Max) 10 T.M.D.S. data1+
Backlight : 4 CCFL 11 T.M.D.S. data1 shield
Power supply 12 No Connect
13 No Connect
AC/DC Power adapter : +16V DC/3.95A (100V~240V) 14 +5V Power
Power consumption : 62 W (Max) w/o subwoofer, 100W(Max) with
15 Ground (for +5V) - Cable detect
subwoofer
Power cord length and type : 1.8M, UK type 16 Hot plug detect
Power indicator : LED (On: Green ,Sleeping mode: Amber ) 17 T.M.D.S. data0-
DPMS : 18 T.M.D.S. data0+
( OFF modes is just for PC mode ) 19 T.M.D.S. data0 shield
STATUS H-sync V-sync Video Power LED 20 No Connect
Green /With 21 No Connect
22 T.M.D.S clock shield
On On On Active <100 W Audio and sub-
23 T.M.D.S. clock+
woofer (Note 1)
24 T.M.D.S. clock-
Green / Without
On On On Active <62W
subwoofer Environmental conditions
Amber LCD
Off Off On Blanked <2W (Note 2) Operating
