Image preview - the first page of the document
>> Download 230W5VS00_ET-SB-EX-SI_1350903357 documenatation <<
Text preview - extract from the document
230W5 LCD Colour Monitor 230W5
Service
Service
Service
230W5VS/00
Horizontal frequencies
TABLE OF CONTENTS 30 - 94 kHz
Description Page Description Page
Important Safety Notice ------------------------------- 2 Wiring diagram--------------------------------------- 31
Technical Data --------------------------------------- 3~4 DVI/DSUB Diagram-----------------------------------32
Connection to PC------------------------------------- ---5 ADC Diagram------------------------------------------33
Front/rear panel components--------------------------6 TMDS RX Master/Slave Diagram----------------34~35
OSD Tree/User Mode-------------------------------- 7~8 Scaler PW 181/172 Diagram-----------------------~36
Attention signals-----------------------------------------9 TMDS TX Diagram--------------- ---------------------37
Troubleshooting------------------ -- --------------10~11 MEMORY/KEY I/O Diagram------------------- -------38
Failure mode of panel----------------------------------12 DDC /CI Diagram--------------------------------------39
Definition of pixel defects-----------------------------13 Power Supply Diagram--------------------------------40
Mechanical Instructions-------------------------- 14~15 Video Decoder Diagram------------------------------41
Display Adjustment------------- ------------------16~17 Power Diagram-----------------------------------42~43
Safety Test Requirements-----------------------------18 Audio board Diagram/C.B.A---------------------44~47
DDC instruction ------------------------------------19~23 Control board/control board C.B.A------------------48
Firmware update for CPU-------------------------24~25 Power/scaler board C.B.A-----------------------49~52
DDC DATA-------------- ----------------------------26~27 Exploded View ----------------------------------------53
Power supply block diagram---------------------------28 Spare parts list----------------------------------- 54~57
Scaler block function---------------------------------- 29 Recommended parts list-- ---------------------------58
Block function----------------------------------------- 30 General Product Specification------------------ 59~80
SAFETY NOTICE
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFORMER FOR THIS UNIT WHEN SERVICING.
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
Published by BU Monitor Printed in Taiwan Copyright reserved Subject to modification M Mar. 15 2004 GB 3138 106 10366
2 230W5 LCD Important Safety Notice
Go to cover page
Proper service and repair is important to the safe, reliable operation
FOR PRODUCTS CONTAINING LASER :
of all PHILIPS Consumer Electronics Company** Equipment. The
service procedures recommended by DANGER- Invisible laser radiation when open.
PHILIPS and described in this service manual are effective methods AVOID DIRECT EXPOSURE TO BEAM.
of performing service operations. Some of these service operations
require the use of tools specially designed for the purpose. The CAUTION- Use of controls or adjustments or
special tools should be used when and as recommended. performance of procedures other than
those specified herein may result in
It is important to note that this manual contains various CAUTIONS hazardous radiation exposure.
and NOTICES which should be carefully read in order to minimize the
risk of personal injury to service personnel. The possibility exists that CAUTION- The use of optical instruments with this
improper service methods may damage the equipment. It is also product will increase eye hazard.
important to understand that these CAUTIONS and NOTICES ARE
NOT EXHAUSTIVE. PHILIPS could not possibly know, evaluate and
advise the service trade of all conceivable ways in which service
might be done or of the possible hazardous consequences of each
way. Consequently, PHILIPS has not undertaken any such broad
evaluation. Accordingly, a servicer who uses a service procedure or TO ENSURE THE CONTINUED RELIABILITY OF THIS
tool which is not recommended by PHILIPS must first satisfy himself PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S REPLACEMENT
thoroughly that neither his safety nor the safe operation of the PARTS, WHICH ARE LISTED WITH THEIR
equipment will be jeopardized by the service method selected. PART NUMBERS IN THE PARTS LIST SECTION OF THIS SERVICE
MANUAL.
* * Hereafter throughout this manual, PHILIPS Consumer
Electronics Company will be referred to as PHILIPS.
WARNING Take care during handling the LCD module with backlight unit
Critical components having special safety characteristics are - Must mount the module using mounting holes arranged in four
identified with a by the Ref. No. in the parts list and enclosed corners.
- Do not press on the panel, edge of the frame strongly or electric
within a broken line*
(where several critical components are grouped in one area) along shock as this will result in damage to the screen.
- Do not scratch or press on the panel with any sharp objects, such
with the safety symbol on the schematics or exploded views.
as pencil or pen as this may result in damage to the panel.
Use of substitute replacement parts which do not have the same - Protect the module from the ESD as it may damage the electronic
specified safety characteristics may create shock, fire, or other circuit (C-MOS).
- Make certain that treatment person s body are grounded through
hazards.
wrist band.
Under no circumstances should the original design be modified or - Do not leave the module in high temperature and in areas of high
altered without written permission from PHILIPS. PHILIPS assumes humidity for a long time.
- Avoid contact with water as it may a short circuit within the
no liability, express or implied, arising out of any unauthorized
module.
modification of design. - If the surface of panel become dirty, please wipe it off with a soft
Servicer assumes all liability.
material. (Cleaning with a dirty or rough cloth may damage the
panel.)
* Broken Line
Technical Data 230W5 LCD 3
Go to cover page
Technical Specifications (2) Input DVI I connector pin assignment
-
1. General
1.1.Product description
The Hudson3 23"TFT flat panel monitor is specified as a display
peripheral with Analog video signal input, Digital video input , CVBS ,
S-video input and YPbPr video input. Horizontal scan range is
30 - 94 KHz and refresh range is 56 - 85 Hz. This scan range
allows it to display resolution up to 1920*1200 non-interlaced at
60 Hz refresh rate. The image can be adjust through OSD control,
these adjustments can be stored on an board memory including 42
preset modes and 20 factory preset modes. All optical
characteristics (including WHITE-D, brightness, and so on) are Pin No. Description
determined according to panel specification after warming up 1 TMDS data2 -
approximate 30 minutes that brightness stability is optimal, and 2 TMDS data2+
follow strictly after panel specification. 3 TMDS data2 shield
1.2Destination : US*.CA*. Z9 4 NC
1.3.Basic data
1.3.1 LCD panel
5 NC
Type NR.: LM230W02(LG.PHILIPS) 6 DDC clock
Outside dimensions : 523.4(w)335.6(h)41(d) (Typ) mm 7 DDC data
Pitch ( mm ): 0.258 (per one triad) x 0. 258mm 8 Analog V-sync
Color pixel arrangement: RGB vertical stripes 9 TMDS data1-
Display surface: low reflection, antiglare with hard coating 10 TMDS data1+
Color depth : 16777216 colors (8 bits) 11 TMDS data1 shield
Backlight: 12 CCFL's
Active area(WxH): 495x309mm (23" diagonal)
12 NC
View angle: Horizontal & Vertical 176 degree (CR>=10) 13 NC
Contrast ratio: 500:1(typ.) 350:1(min.) 14 +5V
White luminance: Panel original color >200nits (min), 250 nits (Typ.) 15 Ground(return for +5V and H/Vsync)
1.3.2.Power supply 16 Hot plug detect
Main voltage: AC 90 - 135 Vrms and 170 264 Vrms, 50/602 Hz 17 TMDS data0 -
Power consumption: Less than 90 Watts
18 TMDS data0+
Operating <90W(max), standby<2.5W
DC power switch off < 2W 19 TMDS data0 shield
Power cord length: 1.8M 20 NC
Power cord type: 3 lead with earth plug 21 NC
Power indicator: LED (ON: blue, Standby: amber, NEW MODE: 22 TMDS clock shield
flashing blue twice per second before user adjust and save it.). 23 TMDS clock+
Auto power saving: EPA, Nutek, VESA DPMS 24 TMDS clock-
1.3.3.Horizontal scan : 30 - 94 KHz
1.3.4.Vertical scan : 56 - 85 Hz C1 Analog R
1.3.5 Pixel clock : 205MHz for analog input, 165MHz for digital input. C2 Analog G
1.3.6.Input signals C3 Analog B
1.Signal input level C4 Analog H-sync
Video : 0.7 Vp-p Linear / 75 ohms C5 Analog GND (Analog R, G, B Return)
Sync : H/H+V, V TTL level, composite sync,
sync on green Impedance Signal interface
Video : Terminated with 75 ohms - 15Pins, D-sub male with DDC2B Pin assignments
Sync : Terminated with 2K2 ohms - 29Pins, DVI-I male with DDC2B Pin assignments
2. CVBS Video : 1Vp-p,75 Ohm Sync polarity :
3. S-Video : Y-1Vp-p,75 ohms C-0.3Vp-p,75 ohms -Hori.sync positive/negative
4. YPbPr : Y : 700mV , 75 Ohm Pb, Pr : +/- 350mV. 75 Ohm -Vert.syncpositive/negative
5. Audio Signal : For S-terminal/CVBS/YPbPr 3) CVBS
use L/R audio input PC line in The input signals are applied to display through CVBS cable
1.3.7 The PC input signals can be applied in two different modes : Pin assignment
1).VESA Analog
Input signal : Video, Hsync., Vsync
Video : 0.7 Vp-p, input impedance, 75 ohm @DC
PIN NO. SIGNAL
Sync. : Separate sync TTL level , input impedance 5k ohms 1 GND
Hor. sync Positive/Negative 2 CVBS
Ver. sync Positive/Negative
2). Intel DVI Digital 3 CVBS
Input signal : Four channel TMDS signals 4 CVBS
1.3.8 Input connectors (4) S-Video
(1) Input analog D-sub connector pin assignment The input signals are applied to display through S-Video cable
Pin Description Pin Description
Pin assignment
5 1
No
1 Red
No
9 DDC +5V
PIN NO. SIGNAL
1 GND
2 Green/SOG 10 Cable detect(Gnd)
6
3 Blue 11 Sense GND
2 GND
10 3 GND
4 Sense(Ground) 12 Bi-directional data
5 NC 13 H/H+V Sync
15 11 4 GND
6 Red Gnd 14 V Sync 5 GND
7 Green Gnd 15 Data clock
6 LUMA
8 Blue Gnd
8 CHROMA
4 230W5 LCD Technical Data(Continued)
Go to cover page
5) Component Video Measure YA. Then output Pattern 3 and measure YB.
The input signals are applied to display through Component Video the cross talk value :
RCA Jack pin assignment ABS( YA - YB )
PIN NO. SIGNAL
X 100% < 2.0 %
1 GND YA
