Image preview - the first page of the document
>> Download BDL6545AT documenatation <<
Text preview - extract from the document
65 inch FHD LCD PUBLIC DISPLAY
BDL6545AT/00
Horizontal frequencies
31 - 8 3 kHz
TABLE OF CONTENTS
Description Page Description Page
Important Safety Notice--------------------------------------2 Wiring Diagram-----------------------------------------49~51
Technical Data--------------------------------------------------3 Block Diagram-------------------------------------------52~53
Installation----------------------------------------------------4~7 Scaler Diagram & C.B.A. -----------------------------54~62
Troubleshooting------------------------------------------------8 Power Diagram & C.B.A. ----------------------------63~64
On Screen Display----------------------------------------9~14 Control Diagram & C.B.A. ----------------------------65~66
Philips Pixel Defect Policy ---------------------------------15 General product specification---------------------67~128
Mechanical Instructions ------------------------------16~26 Exploded V iew ---------------------------------------------129
Spare/ Recommended P arts List-----------------------130
Color adjustment ---------------------------------------27~29
!
Electrical instruction ----------------------------------30~32 PCBA photos-------------------------------------------------131
Service Tool-----------------------------------------------33~34 Repair tips---------------------------------------------132~133
DDC Instructions & Serial Number -----------------35~42 Repair Flow chart------------------------------------134~139
DDC DATA ----------------------------------------------------43 Safety Test Requirments---------------------------------140
Firmware Upgrade for CPU-- -------------------------44~47 Appendix:Touch Function Trouble Shooting--141~146
Failure Mode Of Panel - ------------------------------------48 Appendix:Touch Function Calibration Procedure-147~158
SAFETY NOTICE
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOL TAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFORMER FOR THIS UNIT WHEN SERVICING.
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
Published by Philips Consumer Lifestyle Copyright reserved Subject to modification July,23 2012 GB
2 BDL6545AT LCD
Important Safety Notice
Proper s ervic e and repair is important to the safe, reliable
FOR PRODUCTS CONTAINING LASER :
operation of all Philips Consumer Electronics Company
equipment. The service procedures recommended by Philips and DANGER - Invisible laser radiation when open.
described in this service manual a re eff ective methods of AVOID DIRECT EXPOSURE TO BEAM.
performing service operations . Some of these service CAUTION - Use of controls or adjustments or
operations require the us e of tools speciall y desi gned for the
performance of procedures other than
purpose. The special tools should be used when and as
those specified herein may result in
recomm ended.
hazardous radiation exposure.
It is im portant to note that this m anual c ontains various
CAUTI ONS and NOTICES which should becarefully read in CAUTION - The use of optical instruments with this
order to m inimize the risk of personal injury to service product will increase eye hazard.
personnel . The possibility exists that improper service
methods may damage the equipment. It is also important to
underst and that these CAUTIONS and NOTICES ARE NOT
EXHAU STIVE. Philips could not possibly know, evaluate and
TO ENSURE THE CONTINUED RELIABILITY OF THIS
advise the servic etrade of all conceivable ways i n which
service might be done or of the possible hazardous PRODUCT , USE ONLY ORIGINAL MANUFACTURER'S
consequences of each way. Consequently, Philips has not REPLACEMENT PAR TS, WHICH ARE LISTED WITH THEIR PART
undertaken any such broad evaluation. Accordingly, NUMBERS IN THE PARTS LIST SECTION OF THIS
who uses a servi ce procedure or tool which is not SERVICE MANUAL.
recommended by Philips must first satisfy himself thoroughly that
neither his safety nor the safe operation of the equipment will
be jeopardized by the service method selected.
* * Hereafter throughout this manual, Philips Consumer
Electronics Company will be referred to as Philips . * *
Take care during handling the LCD module with backlight
unit
- Must mount the module using mounting holes arranged in four
WARNING
corners.
- Do not press on the panel, edge of the frame strongly or electric
Critical components having special safety characteristics are shock as this will result in damage to the screen.
identified with a by the Ref. No. in the parts list and
- Do not scratch or press on the panel with any sharp objects, such
enclosed within a broken line
as pencil or pen as this may result in damage to the panel.
(where several critical components are grouped in one area)
- Protect the module from the ESD as it may damage the electronic
along with the safety symbol on the schematics or
circuit (C -MOS).
exploded views.
Use of substitute replacement parts which do not have the - Make certain that treatment body are grounded through
same speci fied safety characteristic s may create shock, fire, wrist band.
or other hazards . - Do not leave the module in high temperature and in areas of high
Under no circumstances should the original design be humidity for a long time.
modified or altered without written permission from Philips.
- Avoid contact with water as it may as hort circuit within the module.
Philips assumes no liability, express or implied, arising out of
- If the surface of panel become dirty, please wipe it off with a soft
any unauthorized modification of design.
material. (Cleaning with a dirty or rough cloth may damage the
Servicer assumes all liability.
panel.)
BDL6545AT LCD 3
Technical Data
AUO
LCD Panel AUO P645HW04 V0 Interface Requirement
LCD size 65" inch
Display Resolution 1920(H) x 1080(V)
Display Area 1428.48(H) x 803.52 (V) mm
Pixel Pitch 0.744 mm
178 degree (Horizontal)/ 178 degree Configuration
Viewing Angle External Connector
(Vertical) with MVA technology
Input Output
Display Response Time
8 msec (Typ.) 1 1
(Tr+Tf)
Display Color 1073.7M (8bits+FRC) Power (AC)
Contrast Ratio 5000:1(Typ)
Luminance 500 cd/m2 (Typ.)
Lamp Life Time 50,000hrs (Min.)
Power hard switch
0
Features
1
Features Description
1 1
Max & Native Panel Resolution 1920 x 1080 @ 60 Hz
8-bit 162MHz ADC Yes VGA (D-sub)
Picture in Picture(PIP) Yes
3D comb-filter, 3D De-interlace Yes 1 0
Fully Programmable White
Yes DVI
Balance functions
Enhanced H & V Sharpness Yes
PC Auto Phase adjustment and 1
Yes Audio (PC) 0
Auto Mode Detect
Advanced video enhance. noise 1
Yes 0
reduction
RS232 control in and out Yes HDMI
Screen saver with image sticking
Yes
protection (Image Retention) 1 1
VGA input and output Yes Component (YPbPr)
TV wall support up to 5x5 Yes
Remote control lock in OSD Yes
2
Front panel keypad lock Yes
Scheduling Yes 2
IR Pass Yes Audio (RCA/YPbPr) x1
HDMI Overscan Yes
Auto Adjustment Yes x1
1 1
Power Requirement RS232
Power Supply Built-in AC power board
By pass AC plug-in for external BOX PC 1 1
Power Cable Detachable AC power cord AV (VIDEO)
Power Supply AC power adaptor: 90~264V AC 50/60Hz BNC/CBVS
Voltage
Power Consumption Power ON mode: < 550 W 1 0
Standby mode: < 0.5 W S-Video
Off mode < 0.5 W
DPMS Support
Power Saving Mode <0.5 W
Power Control On/off control via IR/RS232/Push button Environment Requirement
Operating Condition
Operating Temperature Temperature 0 to 40 degrees
Relative Humidity: 85%@50
Humidity
(non-condensing)
Altitude 0 meter to +3000 meters above sea level
Storage Condition
Temperature Temperature-20 to 60 degree
Relative Humidity: 10~85%@50
Humidity
(non-condensing)
Altitude 0 meter to 12,000 meters above sea level
4 BDL6545AT LCD
Installation
Front View Product Description 7. Smart Insert installation holes
Location for the Smart Insert (for integration of a small form factor PC)
and M4 screws. (Maximum load: 2kg)
8. Carrying handle
Use these handles when carrying the display by hand.
9. Cable retainer installation holes
Install the cable retainer using these holes.
Input/ Output Terminals
1. Remote control sensor, ambient light sensor and power indicator
