Image preview - the first page of the document
BDL3215E-BDL4225E维修手册


>> Download BDL3215E-BDL4225E维修手册 documenatation <<

Text preview - extract from the document
  32&42 Flat Wide Monitor

  Service                                                          BDL3215E/00
  Service                                                          BDL4225E/00
  Service




  Description                                                           Page Description                                                                Page

Table of Contents.........................................................1      6.2 Power Board............................................................50
Revision List................................................................2   6.3 IR Board..........................................................55
Safety Instructions....................................................3         6.4 Key Board......................................................56
1. General Specifications...............................................7        7. PCB Layout......................................................57
2. Flat Wide Monitor Description.................................11              7.1 Scaler Board...................................................57
3. Operation Instructions..............................................12        7.2 Power Board...................................................59
3.1 Control Panel................................................12              7.3 IR Board.........................................................62
3.2 Terminal Panel.......................................................13      7.4 Key Board......................................................63
3.3 Remote Control..............................................14
                                                                                 8. Wiring Diagram.................................................64
3.4 OSD Controls...................................................15
                                                                                 9. Scaler Board Overview.......................................66
4. Input/output Specification.......................................28
                                                                                 10. Mechanical Instructions.....................................67
4.1 Input Signal Connector.........................................28
                                                                                 11. Trouble Shooting.............................................76
4.2 Factory Preset Display Modes................................29
                                                                                 12. ISP Instructions.........................................................78
4.3 Pixel Defect Policy..........................................31
4.4 Failure Mode of Panel .....................................34                13. DDC Instructions.......................................................81
5. Block Diagram..........................................................35     14. White Balance, Luminance Adjustment..................101
5.1 Scaler Board..........................................................35     15. Monitor Exploded View...........................................103
5.2 Power Board..........................................................36      16. Recommended & Spare Parts List..........................105
6. Schematic Diagram..................................................37         17. General Product Specification..........................149
6.1 Scaler Board...............................................37

                                                                      SAFETY NOTICE
      ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE
      CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN
      SERVICING ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.


         CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING


         REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES

         Copyright 2010 Philips Consumer Lifestyle         Subject to modification K        Jan. 22, 2010
2
                                       Revision List
Version   Release Date   Revision History

    A00   Jan. 22,2010   Initial release, Draft Version

    A01   Jan.25,2010    Update the PCB layout

    A02   Feb.22,2010    Update the DDC Instructions and power cord descriptions

                         Add power cord 089G414A18N
    A03   Apr.02,2010
                         Change IR Board to IRPCAQP2 for BDL4225E/00

    A04   May.11,2010    Add spare parts list for BDL3215E/00 and update ISP Instructions

    A05   Nov.18,2010    Update the DDC Instructions on page 84
                                                                                                                3
Safety Instructions
Warnings and Precautions




CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.


        This symbol indicates high voltage is present inside. It is dangerous to make any kind of contact with any
inside part of this product.


        This symbol alerts you that important literature concerning operation and maintenance has been included
with this product.


Note to CATV system installer: This reminder is provided to call CATV system installer's attention to Article
820-40 of the National Electrical Code (Section 54 of Canadian Electrical Code, Part I), that provides guidelines for
proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of
the building as close to the point of cable entry as practical.


CAUTION: FCC/CSA regulations state that any unauthorized changes or modifications to this equipment may void
the user's authority to operate it.


CAUTION: To prevent electric shock, match the wide blade of plug to the wide slot, and fully insert the plug.


Important: One Federal Court has held that unauthorized recording of copyrighted TV programs is an infringement
of U.S. copyright laws. Certain Canadian programs may also be copyrighted and any unauthorized recording in
whole or in part may be in violation of these rights.


TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
   4
Read and follow these instructions when connecting and using your computer monitor:




   Unplug the monitor if you are not going to use it for an extensive period of time.
   Unplug the monitor if you need to clean it with a slightly damp cloth. The screen many be wiped with a dry cloth
   when the power is off. However, never use alcohol, solvents or ammonia-based liquids.
   Consult a service technician if the monitor does not operate normally when you have followed the instructions in
   this manual.
   The casing cover should be opened only by qualified service personnel.
   Keep the monitor out of direct sunlight and away from stoves or any other heat source.
   Remove any object that could fall into the vents or prevent proper cooling of the monitor's electronics.
   Do not block the ventilation holes on the cabinet.
   Keep the monitor dry. To avoid electric shock, do not expose it to rain or excessive moisture.
   If turning off the monitor by detaching power cable or DC power cord, wait for 6 seconds before attach the
   power cable or DC power cord for normal operation.
   To avoid the risk of shock or permanent damage to the set do not expose the monitor to rain or excessive
   moisture.
   When positioning the monitor, make sure the power plug and outlet are easily accessible.
   IMPORTANT: Always activate a screen saver program during your application. If a still image in high contrast
   remains on the screen for an extended period of time, it may leave an `after-image' or `ghost image' on the front
   of the screen. This is a well-known phenomenon that is caused by the shortcomings inherent in the LCD
   technology. In most cases the afterimage will disappear gradually over a period of time after the power has
   been switched off. Be aware that the after-image symptom cannot be repaired and is not covered under
   warranty.


Regulatory Information

CE Declaration of Conformity
MMD declare under our responsibility that the product is in conformity with the following standards.
   EN60950-1: 2001 (Safety requirement of Information Technology Equipment)
   EN55022: 2006 (Radio Disturbance requirement of Information Technology Equipment)
   EN55024:1998+A:2001+A2: 2003 (Immunity requirement of Information Technology Equipment)
   EN61000-3-2:2006 (Limits for Harmonic Current Emission)
   EN61000-3-3:1995+A1: 2001+A2:2005 (Limitation of Voltage Fluctuation and Flicker) following provisions of
   directives applicable.
   2006/95/EC (Low Voltage Directive)
   2004/108/EC (EMC Directive)
   93/68/EEC (Amendment of EMC and Low Voltage Directive) and is produced by a manufacturing organization
   on ISO9000 level.
                                                                                                                      5
Federal Communications Commission (FCC) Notice (U.S. Only)
            This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
            to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
            interference in a residential installation. This equipment generates uses and can radiate radio frequency
            energy and, if not installed and used in accordance with the instructions, may cause harmful interference
            to radio communications. However, there is no guarantee that interference will not occur in a particular
            installation. If this equipment does cause harmful interference to radio or television reception, which can
            be determined by turning the equipment off and on, the user is encouraged to try to correct the
            interference by one or more of the following measures:
             Reorient or relocate the receiving antenna.
             Increase the separation between the equipment and receiver.
             Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
             Consult the dealer or an experienced radio/TV technician for help.

            Changes or modifications not expressly approved by the party responsible for compliance could void the
            user's authority to operate the equipment.


Use only RF shielded cable that was supplied with the monitor when connecting this monitor to a computer device.
To prevent damage which may result in fire or shock hazard, do not expose this appliance to rain or excessive
moisture.

THIS CLASS B DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE CANADIAN INTERFERENCE-
CAUSING EQUIPMENT REGULATIONS.

            This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
            1) This device may not cause harmful interference.
            2) This device must accept any interference received, including interference that may cause undesired
               operation.


Information for UK only
                                    WARNING - This appliance must be earthed.
                                    Important:
                                    This apparatus is supplied with an approved mould 13A plug. To change fuse in
                                    this type of plug proceed as follows:
                                    1. Remove fuse cover and fuse.
                                    2. Fit new fuse which should be a BS 1362 5A, A.S.T.A. or BSI approved type.
                                    3. Refit the fuse cover.
                                    If the fitted plug is not suitable for your socket outlets, it should be cut off and an
                                    appropriate 3-pin plug fitted in its place.
                                    If the mains plug contains a fuse, this should have a value of 5A. If a plug without
                                    a fuse is used, the fuse at the distribution board should not be greater than 5A.
Note: The severed plug must be destroyed to avoid a possible shock hazard should it be inserted into a 13A socket
elsewhere.
   6
                                  How to connect a plug
                                  The wires in the mains lead are colored in accordance with the following code:
                                  BLUE - "NEUTRAL" ("N")
                                  BROWN - "LIVE" ("L")
                                  GREEN & YELLOW - "EARTH" ("E")
                                  1. The GREEN AND YELLOW wire must be connected to the terminal in the
                                      plug which is marked with the letter "E" or by the Earth symbol or colored
                                      GREEN or GREEN AND YELLOW.
                                  2. The BLUE wire must be connected to the terminal which is marked with the
                                      letter "N" or colored BLACK.
                                  3. The BROWN wire must be connected to the terminal which marked with the
                                      letter "L" or colored RED.
                                  Before replacing the plug cover, make certain that the cord grip is clamped over
                                  the sheath of the lead - not simply over the three wires.


North Europe (Nordic Countries) Information
End-OF-Life Disposal
Your new TV/Monitor contains materials that can be recycled and reused. Specialized companies can recycle your
product to increase the amount of reusable materials and to minimize the amount to be disposed of.
Please find out about the local regulations on how to dispose of your old monitor from your local Philips dealer.


For Customers in Canada and USA
This product may contain lead and/or mercury. Dispose of in accordance to local-state and federal regulations.
For additional information on recycling contact www.eia.org (Consumer Education Initiative)


Waste Electrical and Electronic Equipment-WEEE
Attention users in European Union private households
                      This marking on the product or on its packaging illustrates that, under European Directive
                      2002/96/EG governing used electrical and electronic appliances, this product may not be
                      disposed of with normal household waste. You are responsible for disposal of this
                      equipment through a designated waste electrical and electronic equipment collection. To
                      determine the locations for dropping off such waste electrical and electronic, contact your
                      local government office, the waste disposal organization that serves your household or the
                      store at which you purchased the product.


Attention Users in United States:
Like all LCD products, this set contains a lamp with Mercury. Please dispose of according to all Local, State and
Federal Laws. For the disposal or recycling information, contact: www.mygreenelectronics.com or www.eiae.org.
                                                                                                         7
1. General Specifications
BDL3215E

                    Diagonal:                    32 / 80 cm diagonal

                    Pixel Pitch:                 0.511 mm / 0.51075(H)x0.51075(V)

                    Resolution:                  1366 x 768 dots

                    Color:                       Over 16 million colors (depending on video card used)

                    Display Colors:              8bit-16.7M
LCD Module
                    Brightness:                  450 cd/m2(typ.)

                    Contrast Ratio:              3000:1 (typ.)

                    Response time:               8ms (typ.)

                    Viewing Angle:               89
