Image preview - the first page of the document



>> Download p04 documenatation <<

Text preview - extract from the document

  4      105S2 CM23 GSIII                                         Installation
9 Go to cover page

                                                                           On-Screen Display
Front View
                                                                           Description of the On-Screen Display The OSD
                                                                           Tree The OSD Controls


                                                                           Description of the On Screen Display
                                                                           What is the On-Screen Display?
                                                                           This is a feature in all Philips monitors which allows an
                                                                           end-user to adjust screen performance of monitors
                                                                           directly though an on-screen instruction window. The user
                                                                           interface provides user-friendliness and ease-of-use
                                                                           when operating the monitor.


                                                                           Basic and simple instruction on the control keys.
                                                                           On the front controls of your monitor, once you press the
                                                                              button, the On Screen Display (OSD) Main Controls
                                                                           window will pop up and you can now start making
         Power button switches your monitor on.
                                                                           adjustments to your monitor's various features. Use the
         OK button which when pressed will take you to the OSD                 or    the keys to make your adjustments within.
         controls
         Contrast hotkey. When the UP arrow is pressed, the
         adjustment controls for the CONTRAST will show up.
         UP and DOWN buttons are used when adjusting the OSD of
         your monitor
         Brightness hotkey. When both the LEFT and RIGHT arrows
         are pressed at the same time, then the adjustment controls for
         BRIGHTNESS will show up.
         LEFT and RIGHT buttons, like the UP and DOWN buttons, are
         also used in adjusting the OSD of your monitor.


Rear View




1. Power in - attach power cable here.
2. Video In - this is a cable which is already attached to your monitor.
Connect the other end of the cable to your PC.

3Back                                                                                                                      Forward4
