Image preview - the first page of the document
>> Download 25gs3-p06~p14(DFU) documenatation <<
Text preview - extract from the document
6 107P2 CM25 GSIII OSD Adjustments
Go to cover page
The OSD Controls
1) Press the button on the monitor. The MAIN CONTROLS window
appears. LANGUAGE should be highlighted.
BRIGHTNESS 2) Press the button again. The LANGUAGE window appears.
To adjust your screen's brightness, follow the steps below. Brightness is
the overall intensity of the light coming from the screen. A 50%
brightness is recommended.
1) Press the or button on the monitor. The BRIGHTNESS window
appears.
2) Press the or button to adjust the brightness.
3) When the brightness is adjusted to the level desired, stop pressing 3) Press the or button until the desired language is highlighted.
the or button and after three seconds the BRIGHTNESS window
will disappear with the new adjustment saved.
Smart Help After the BRIGHTNESS window has disappeared, to
continue to the CONTRAST window, follow the steps under
CONTRAST.
CONTRAST
To adjust your screen's contrast, follow the steps bellow. Contrast is the
difference between the light and dark areas on the screen. A 100%
contrast is recommended. 4) Press the button to confirm your selection and return to MAIN
CONTROLS window. CLOSE MAIN CONTROLS will be highlighted...
1) Press the or button on the monitor. The CONTRAST window
appears. Smart Help After returning to MAIN CONTROLS . . .
. . . to continue to INPUT SIGNAL SELECTION, press the button until
INPUT SIGNAL SELECTION is highlighted. Next, follow steps 3 - 5
under INPUT SIGNAL SELECTION.
. . . to exit completely, press the button
INPUT SIGNAL SELECTION (Not available in all models)
INPUT SIGNAL SELECTION determines what you see on the screen.
The default setting is INPUT A, but if the video input signal is different
that the output signal, you may want to change it to INPUT B.?
1) Press the button on the monitor. The MAIN CONTROLS window
appears.
2) Press the or button to adjust the contrast. 2) Press the button until INPUT SIGNAL SELECTION is highlighted.
3) When the contrast is adjusted to the level desired, stop pressing the
or button and after three seconds the CONTRAST window will
disappear with the new adjustment saved.
Smart Help After the CONTRAST window has disappeared, to
continue to the MAIN CONTROLS, follow the steps under LANGUAGE
LANGUAGE
The ON SCREEN DISPLAY shows its settings in one of five languages.
The default is English, but you can select French, Spanish, German, or
Italian.
Back Forward
OSD Adjustments 107P2 CM25 GSIII 7
Go to cover page
3) Press the button. The INPUT SIGNAL SELECTION window
appears.
4) Press the or button to highlight INPUT B or INPUT A.
5) Press the button to confirm your selection and return to the MAIN
CONTROLS window. CLOSE MAIN CONTROLS will be highlighted.
Smart Help After returning to MAIN CONTROLS . . .
. to continue to ZOOM, press the button until ZOOM is highlighted.
Next, follow steps 3 - 5 under ZOOM. 3) Press the button. The ADJUST HORIZONTAL window appears.
. . . to exit completely, press the button ADJUST POSITION should be highlighted.
ZOOM
ZOOM increases or decreases the size of the images on your screen.
To adjust the ZOOM follow the steps below.
1) Press the button on the monitor. The MAIN CONTROLS window
appears.
2) Press the button until ZOOM is highlighted.
4) Press the or button to move the image to the left or right.
5) When the position is adjusted, press the button to return to MAIN
CONTROLS window, or press the to highlight ADJUST SIZE.
3) Press the button. The ZOOM window appears.
4) Press the or button to adjust ZOOM. 6) To adjust the horizontal size, press the or button.
5) Press the button to confirm your selection and return to the MAIN 7) When the size is adjusted, press the button to return to MAIN
CONTROLS window. CLOSE MAIN CONTROLS will be highlighted. CONTROLS window. CLOSE MAIN CONTROLS will be highlighted.
Smart Help After returning to MAIN CONTROLS . . . Smart Help After returning to MAIN CONTROLS . . .
. . . to continue to ADJUST HORIZONTAL, press the button until . . . to continue to ADJUST VERTICAL, press the button until ADJUST
ADJUST HORIZONTAL is highlighted. Next, follow steps 3 - 7 under VERTICAL is highlighted. Next, start with step 3 under ADJUST
ADJUST HORIZONTAL. VERTICAL and follow the directions.
. . . to exit completely, press the button . . . to exit completely, press the button
ADJUST HORIZONTAL
ADJUST POSITION under ADJUST HORIZONTAL shifts the image on ADJUST VERTICAL
your screen either to the left or right. Use this feature if your image ADJUST POSITION under ADJUST VERTICAL shifts the image on
does not appear centered. ADJUST SIZE under ADJUST your screen either up or down. Use this feature if your image does not
HORIZONTAL expands or controls the image on your screen, pushing it appear centered. ADJUST SIZE under ADJUST VERTICAL expands or
out toward the left and right sides or pulling it in toward the center. controls the image on your screen, pushing it out toward the top or
1) Press the button on the monitor. The MAIN CONTROLS window bottom or pulling it in toward the center.
appears. 1) Press the button on the monitor. The MAIN CONTROLS window
2) Press the button until ADJUST HORIZONTAL is highlighted. appears.
Back Forward
8 107P2 CM25 GSIII OSD Adjustments
Go to cover page
2) Press the button until ADJUST VERTICAL is highlighted. 2) Press the button until ADJUST SHAPE is highlighted.
3) Press the button. The ADJUST VERTICAL window appears. 3) Press the button. The ADJUST SHAPE window appears.
ADJUST POSITION should be highlighted. ADJUST SIDE CURVE should be highlighted.
4) Press the button. The SIDE CURVE window appears.
PINCUSHION should be highlighted.
4) Press the or button to move the image up or down.
5) When the position is adjusted, press the button to return to MAIN
CONTROLS window, or press the to highlight ADJUST SIZE.
5) To adjust the pincushion, press the or button.
6) To adjust the vertical size, press the or button. 6) When the pincushion is adjusted, press the button to highlight
BALANCED or press the button to return to the ADJUST SHAPE
7) When the size is adjusted, press the button to return to MAIN window.
CONTROLS window. CLOSE MAIN CONTROLS will be highlighted.
Smart Help After returning to MAIN CONTROLS . . .
. . . to continue to ADJUST SHAPE, press the button until ADJUST
SHAPE is highlighted. Next, start with step 3 under ADJUST SHAPE
and follow the directions.
. . . to exit completely, press the button
ADJUST SHAPE
ADJUST SIDE CURVE
ADJUST SIDE CURVE under ADJUST SHAPE allows you to adjust two
of the five preset options. These two options are PINCUSHION and
BALANCED pincushion. Note: use these features only when the picture 7) To adjust the balanced pincushion, press the or button.
is not square.
8) When the balanced pincushion is adjusted, press the button to
1) Press the button on the monitor. The MAIN CONTROLS window return to the ADJUST SHAPE window. BACK TO MAIN WINDOWS will
appears. be highlighted.
9) Press the button to return to the MAIN CONTROLS window, or
press the button until ADJUST SIDE ANGLES is highlighted.
Back Forward
OSD Adjustments 107P2 CM25 GSIII 9
Go to cover page
Smart Help After returning to MAIN CONTROLS . . . 7) When the trapezoid is adjusted, press the button to highlight
...to continue to ADJUST SIDE ANGLES, start with step 5 under PARALLELOGRAM or press the button to return to the ADJUST
ADJUST SIDE ANGLES and follow the directions.
...to exit completely, press the button twice.
...to adjust only the BALANCED pincushion, follow steps 1 - 4 above,
then press the button, and follow steps 7 - 9.
...to adjust only the PARALLELOGRAM, follow steps 1 - 4 above, then
press the button, and follow steps 7 -9
ADJUST SIDE ANGLES
ADJUST SIDE ANGLES under ADJUST SHAPE allows you to adjust
two of the five preset options. These two options are TRAPEZOID and
PARALLELOGRAM. Note: use these features only when the picture is
not square.
1) Press the button on the monitor. The MAIN CONTROLS window 8) To adjust the parallelogram, press the or button.
appears. 9) When the parallelogram is adjusted, press the button to return to
2) Press the button until ADJUST SHAPE is highlighted. the ADJUST SHAPE window. BACK TO MAIN WINDOWS will be
highlighted.
10) Press the button to return to the MAIN CONTROLS window, or
press the button until ROTATE IMAGE is highlighted.
Smart Help After returning to MAIN CONTROLS . . .
...to continue to ROTATE IMAGE, start with step 5 under ROTATE
IMAGE and follow the directions.
...to exit completely, press the button twice.
...to adjust only the PARALLELOGRAM, follow steps 1 - 4 above, then
press the button, and follow steps 7 -9
ROTATE IMAGE (Not available in all models)
ROTATE IMAGE under ADJUST SHAPE allows you to adjust one of
the five preset options. These two options are PINCUSHION and
BALANCED pincushion. Note: use this feature only when the picture is
not square.
1) Press the button on the monitor. The MAIN CONTROLS window
appears.
3) Press the button. The ADJUST SHAPE window appears. 2) Press the button until ADJUST SHAPE is highlighted.
ADJUST SIDE CURVE should be highlighted.
4) Press the button to highlight ADJUST SIDE ANGLES.
5) Press the button. The SIDE ANGLES window appears.
TRAPEZOID should be highlighted. 3) Press the button. The ADJUST SHAPE window appears.
ADJUST SIDE CURVE should be highlighted.
4) Press the arrow until ROTATE IMAGE is highlighted.
6) To adjust the trapezoid, press the or button.
SHAPE window.
Back Forward
10 107P2 CM25 GSIII OSD Adjustments (Continued)
Go to cover page
5) Press the button. The ROTATE IMAGE window appears. ROTATE 4) Press the or button to highlight 9300K for GENERAL USE,
should be highlighted. 6500K for GAMES, or USER PRESET.
5) Once you have highlighted GENERAL USE or GAMES, press the
button to confirm you selection and return to the MAIN CONTROLS
window. CLOSE MAIN CONTROLS will be highlighted.
6) To adjust the rotation, press the or button.
7) When the rotation is adjusted, press the button to return to the
ADJUST SHAPE window. BACK TO MAIN CONTROLS should be
highlighted.
8) Press the button to return to MAIN CONTROLS.
Smart Help After returning to MAIN CONTROLS . . .
. . . to continue to ADJUST COLOR, press the button until ADJUST
COLOR is highlighted. Next, start with step 3 under ADJUST COLOR
and follow the directions.
6a) ?If USER PRESET is highlighted, press the button to highlight
...to exit completely, press the button twice. RED. Next, press the or button to
adjust the color red.
ADJUST COLOR 6b) ?When finished with RED, press the button to highlight GREEN.
Next, press the or button to adjust the color green.
Your monitor has two preset options you can choose from. The first
option is for GENERAL USE, which is fine for most applications. The 6c) ?When finished GREEN, press the button to highlight BLUE. Next,
second option is for GAMES, which is for playing computer games. press the or button to adjust the color blue.
When you select one of these options, the monitor automatically adjusts 6d) ?When all adjustments are complete, press the button to confirm
itself to that option. There is also a third option, USER PRESET, which your adjustments and return to the MAIN CONTROLS window. CLOSE
allows you to adjust the colors on your screen to a setting you desire. MAIN CONTROLS will be highlighted.
1) Press the button on the monitor. The MAIN CONTROLS window Smart Help After returning to MAIN CONTROLS. . .
appears.
. . . to continue to RESET TO FACTORY SETTINGS, press the button
2) Press the button until ADJUST COLOR is highlighted. until RESET TO FACTORY SETTINGS is highlighted. Next, start with
step 3 under RESET TO FACTORY SETTINGS.
. . . to exit completely, press the button.
RESET TO FACTORY SETTINGS
RESET TO FACTORY SETTINGS returns everything in all the windows
to factory presets.
1) Press the button on the monitor. The MAIN CONTROLS window
appears.
2) Press the button until RESET TO FACTORY SETTINGS is
highlighted.
3) Press the button. The ADJUST COLOR window appears.
3) Press the button. The RESET TO FACTORY SETTINGS window
appears.
Back Forward
OSD Adjustments (Continued) 107P2 CM25 GSIII 11
Go to cover page
4) Press the or button to select YES or NO. NO is the default. YES ADJUST CONVERGENCE (Not available in all models)
returns all settings to their original factory adjustments.
EXTRA CONTROLS is a set of features, including ADJUST
CONVERGENCE. Convergence is a process by which a color is
created by blending other colors. For example, white is created by
blending red, blue, and green. If these colors do not completely blend
together (converge) then you may see unwanted red, green, or blue
lines or dots. To adjust the convergence, follow the steps below. Note:
Use only if necessary. Remember: you must degauss the monitor
BEFORE adjusting the convergence.
5) Press the button to confirm your selection and return to the MAIN
CONTROLS window. CLOSE MAIN CONTROLS will be highlighted. 1) Press the button on the monitor. The MAIN CONTROLS window
appears.
Smart Help After returning to MAIN CONTROLS . . . 2) Press the button until EXTRA CONTROLS is highlighted.
. . . to continue to EXTRA CONTROLS, press the button until EXTRA
CONTROLS is highlighted. Next, start with step 3 under EXTRA
CONTROLS.
. . . to exit completely, press the button.
EXTRA CONTROLS
DEGAUSS
EXTRA CONTROLS is a set of three features, including DEGAUSS.
Degaussing removes electromagnetic build up that may distort the color
on your screen.
1) Press the button on the monitor. The MAIN CONTROLS window
appears.
2) Press the button until EXTRA CONTROLS is highlighted.
3) Press the button. The EXTRA CONTROLS window appears.
DEGAUSS is highlighted. Note: If you have not degaussed the monitor,
please follow the steps under the Extra Controls - Degauss section of
this manual before adjusting the convergence.
4) Press the button until ADJUST CONVERGENCE is highlighted.
3) Press the button. The EXTRA CONTROLS window appears.
DEGAUSS will be highlighted.
5) Press the button. The ADJUST CONVERGENCE window
appears. ADJUST HORIZONTAL is highlighted.
4) To degauss your screen, press the button. Your screen will be
degaussed, then the MAIN CONTROLS window will reappear. CLOSE
MAIN CONTROLS will be highlighted.
Smart Help After returning to MAIN CONTROLS . . .
. . . to continue to ADJUST MOIRE, press the button until EXTRA
CONTROLS is highlighted. Next, start with step 3 under EXTRA
CONTROLS, ADJUST MOIRE.
. . . to exit completely, press the button.
6) To adjust the horizontal convergence, press the or button.
Back Forward
12 6 107P2 CM 25 GSIII OSD Adjustments (Continued)
Go to cover page
7) When the horizontal convergence is adjusted, press the button to
highlight VERTICAL CONVERGENCE.
8) To adjust the vertical convergence, press the or button.
9) When the vertical convergence is adjusted, press the button to 5) Press the . The ADJUST PURITY window appears. TOP LEFT is
highlighted.
return to the EXTRA CONTROLS window. BACK TO MAIN
CONTROLS is highlighted.
Smart Help
After returning to EXTRA CONTROLS . . .
. . . to continue to ADJUST PURITY, press the button until ADJUST
PURITY is highlighted. Next, start with step 4 under EXTRA
CONTROLS - ADJUST PURITY.
Note: If you have not degaussed the monitor, please follow the steps
under the Extra Controls - Degauss section of this manual before
adjusting the purity.
. . . to exit completely, press the button twice.
ADJUST PURITY (Not available in all models)
EXTRA CONTROLS is a set of features, including ADJUST PURITY. 6) To adjust the top left purity, press the or button.
Purity is a process by which colors appear clear and untainted,
especially in the four corners of the monitor. Purity can be affected by 7) When the top left purity is adjusted, press the button to highlight
such things as the presence of a magnetic source near the monitor or TOP RIGHT.
even by the ambient room temperature. For example, you might see the
color red in a corner of the monitor screen where you should see only a
pure white. To adjust the purity, follow the steps below. Note: Use only if
necessary. Remember: you must degauss the monitor BEFORE
adjusting the purity.
1) Press the button on the monitor. The MAIN CONTROLS window
appears.
2) Press the button until EXTRA CONTROLS is highlighted.
8) To adjust the top right purity, press the or button.
9) When the top right purity is adjusted, press the button to
highlight BOTTOM LEFT.
3) Press the button. The EXTRA CONTROLS window appears.
DEGAUSS is highlighted. Note: If you have not degaussed the monitor,
please follow the steps under the Extra Controls - Degauss section of
this manual before adjusting the purity.
10) To adjust the bottom left purity, press the or
4) Press the button until ADJUST PURITY is highlighted. button.
11) When the bottom left purity is adjusted, press the button to
highlight BOTTOM RIGHT.
Back Forward
OSD Adjustments (Continued) 107P2 CM 25 GSIII 13
Go to cover page
ADJUST MOIRE (Not available in all models)
EXTRA CONTROLS is a set of three features, including ADJUST
MOIRE. Moire is a fringe pattern arising from the interference between
two superimposed line patterns. To adjust your moire, follow the steps
below. Note: Use only if necessary. By activating ADJUST MOIRE,
sharpness can be affected.
1) Press the button on the monitor. The MAIN CONTROLS window
appears.
2) Press the DOWN CURSOR button until EXTRA CONTROLS is
highlighted.
12) To adjust the bottom right purity, press the or button.
13) When the bottom right purity is adjusted, press the button
to return to the EXTRA CONTROLS window. BACK TO MAIN
CONTROLS is highlighted.
Smart Help
After returning to EXTRA CONTROLS . . .
. . . to continue to ADJUST PURITY, press the button until AUTO
CALIBRATE is highlighted. Next, start with step 4 under EXTRA
CONTROLS - AUTO CALIBRATE.
3) Press the button. The EXTRA CONTROLS window appears.
. . . to exit completely, press the button twice. DEGAUSS will be highlighted.
4) Press the button until ADJUST MOIRE is highlighted.
5) Press the button. The ADJUST MOIRE window appears.
HORIZONTAL will be highlighted.
6) To adjust the horizontal moire, press the or button.
Back Forward
14 107P2 CM 25 GSIII OSD Adjustments (Continued)
Go to cover page
7) When the horizontal moire is adjusted, press the button to highlight To lock (disable) OSD function:
VERTICAL.
- Press OSD button " " for over 15 seconds to lock the OSD function.
Release it, then OSD comes on the screen as below.
ATTENTION
CONTROL MENU IS LOCKED
8) To adjust the vertical moire, press the or button. To unlock (enable) OSD function:
9) When the vertical moire is adjusted, press the button to return to - Press OSD button " " for over 15 seconds again to unlock the
the EXTRA CONTROLS window. BACK TO MAIN CONTROLS will be OSD function.
highlighted. Release it, then OSD comes on the screen as below.
Smart Help After returning to MAIN CONTROLS . . . Disable the WARNING SIGNAL &
Access Service mode (burn in mode) :
. . . to exit completely, press the button.
The WARNING SIGNAL of NO SIGNAL INPUT appeared :
CLOSE MAIN CONTROLS -After disconnect the Interface cable of the monitor,then Monitor is powered ON.
- If it is successful, the signal " NO SIGNAL INPUT " comes on the screen again later.
To disable all the WARNING SIGNAL :
- Connect the Interface cable of the monitor (Monitor is ON.).
- If it is successful, then the signal " NO SIGNAL INPUT "disappeared.
Access Service Mode & Burn in mode
Firstly, get into Factory Adjustment Mode.
Push LEFT & RIGHT buttons at the same time for
over 15 seconds and release them.
The factory message appears at the bottom of the
main OSD menu. (for example :107PVE V1.44 000427 ;
00195 is M.T.B.F. in HOUR unit)
00195
107PVE V1.44 000427
- Disconnect the Interface cable of the monitor.
- Push LEFT & RIGHT buttons at the same time,then power ON.
- If it is successful, the signal " "
comes on the screen later. SERVICE MODE
(Background is white.). SERIAL NO: TY 123456
- In the beginning of service mode HOURS : 00021
(full white pattern), the monitor FACTORY VER 1.01 990706
will working at 48kHz of horizontal
frequency,after 55 seconds, it will
switch to 81kHz automatically,
then change mode between
two modes constantly every 55 seconds.
-Leave "burn in MODE" :
. Reconnect the interface cable to PC,
then the "burn in MODE" disappear.
Back Forward
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
