Image preview - the first page of the document



>> Download 107s2-p04 documenatation <<

Text preview - extract from the document

  4      107S2 CM23 GSIII                                         Installation
9 Go to cover page

Front View
                                                                           On-Screen Display
                                                                           Description of the On-Screen Display The OSD
                                                                           Tree The OSD Controls


                                                                           Description of the On Screen Display
                                                                           What is the On-Screen Display?
                                                                           This is a feature in all Philips monitors which allows an end-user to
                                                                           adjust screen performance of monitors directly though an on-screen
                                                                           instruction window. The user interface provides user-friendliness and
                                                                           ease-of-use when operating the monitor.



                                                                           Basic and simple instruction on the control keys.
                                                                           On the front controls of your monitor, once you press the button, the
                                                                           On Screen Display (OSD) Main Controls window will pop up and you
                                                                           can now start making adjustments to your monitor's various features.
                                                                           Use the      or     the keys to make your adjustments within.



         Power button switches your monitor on.
         OK button which when pressed will take you to the OSD
         controls
         Contrast hotkey. When the UP arrow is pressed, the
         adjustment controls for the CONTRAST will show up.
         UP and DOWN buttons are used when adjusting the OSD of
         your monitor
         Brightness hotkey. When both the LEFT and RIGHT arrows
         are pressed at the same time, then the adjustment controls for
         BRIGHTNESS will show up.
         LEFT and RIGHT buttons, like the UP and DOWN buttons, are
         also used in adjusting the OSD of your monitor.


Rear View




                                                                           The OSD Tree

                                                                           Below is an overall view of the structure of the On-Screen Display. You
                                                                           can use this as reference when you want to later on work your way
                                                                           around the different adjustments.




1. Power in - attach power cable here.
2. Video In - this is a cable which is already attached to your monitor.
Connect the other end of the cable to your PC.

      Back                                                                                                                            Forward
