4 109B2 GS3 CM25 Front View and Back View
Go to cover page
Front View Front View
POWER button switches your monitor on 1. Power In - attach power cable here.
2. Video In - this is a cable which is already attached to your monitor.
OK button which when pressed will take you to the OSD Connect the other end of the cable to your PC.
controls
Contrast hotkey. When the UP arrow buttons is pressed,
the adjustment control for the CONTRAST will show up.
UP and DOWN buttons are used when adjusting the
OSD of your monitor
BRIGHTNESS hotkey. When the LEFT and RIGHT
arrow buttons are pressed at the same time, then the
adjustment controls for the BRIGHTNESS will show up.
LEFT and RIGHT buttons, like the UP and DOWN
buttons, are also used in adjusting the OSD of your
monitor.
