                                                     Block Diagram                                                                    109B2 GS3 CM25   21

                                                                                                                                        Go to cover page




                                                                         Video /B
                                           R
                         Flying                             Vedio-E
                         cable 15
                                           G
                                                            TDA4822
                                                                               Pre -Amp           Post-Amp                      CRT
                                            B                                  TDA4886A            LM2405
                         pin D-sub
                           H V
        Function
                            V H
        Key/Cont                                            OSD MTV
        rol Board                                            018N-27
                                                                                    Rotation          EHT/L4990A
        & LED                                                                                           X-RAY
                                      XXX              SDA/SCL
                                                                                DAC
                                               H
       Main /B                                 V
                                                                   CPU                    DAC
                                                                                                            Linearity Control
                                                            WT62P1/DDC1/2B
                                                                                      EEPROM
                                                              SD         SCL
                                                                                      ST24C16
                                  H. freq. : 30 - 97KHz                                                        DAF         S-
                                  V. freq. : 50 - 160Hz                                S-Capacitor Switch
                                                                                                                 Capacitor
                                  Switching power freq.: 77kHz
           Degaussing-
                                  CPU clock freq. : 12MHz
              Ckt
                                                                                                H/O            Horizontal
                                               H             Sync Processor                                    Deflection
                                               V                                                H/O
                                                               TDA 4841                         V/O
                                                                                                                 Vertical
                                       +190
                                        +80
                                                                                                                TDA8177F
         90~264V
                  Power                 +13                                     HUNLOCK
         47~63Hz  Supply                +12                                                                    Muting CKT
                 TEA1504                 +5
                                        -6.3
                                        -13
