4     109P2 GS3 CM25                            Front View and Back View
    Go to cover page

                                                               Front View
Front View




             Power button switches your monitor on.

             OK button which when pressed will take you to
             the OSD controls
             Contrast hotkey. When the UP arrow is pressed,
             the adjustment controls for the CONTRAST will
                                                               1. D-Sub Port - Attach the D-Sub connector that comes with your
             show up.
                                                               monitor here. Other end connects to your PC.
             UP and DOWN buttons are used when adjusting
             the OSD of your monitor                           2. Power in - Attach power cable here.
             Brightness hotkey. When both the LEFT and
             RIGHT arrows are pressed at the same time,        3. USB Port - Attach your USB Upstream cable here. Connect the
             then the adjustment controls for BRIGHTNESS       other end to your USB hub or your PC's USB connector.
             will show up.
             LEFT and RIGHT buttons, like the UP and           4. BNC Connectors - Attach the connectors here to get the best video
             DOWN buttons, are also used in adjusting the      performance from your monitor
             OSD of your monitor.
             By pressing both the UP and OK buttons, you
             can easily access the Input Signals A and/or B.
