                                      Block Diagram                                                                                   107B2 CM24 GSIII   19
                                                                                                                                      9 Go to cover page


                                                        FUNCTION BLOCK OF 107B2

                                                                                                      CRT
          R     TDA4822PS         Video pre-      Video Output                                         &
          G                       amp             Stage LM2435                                   DEFLECTION UNIT
                Light-
          B     Frame             TDA4886
          H
                                                                           ROTATION
        SDA                                      IIC                        LM358N
        SCL                        OSD IC
          V                   MTV18N-27
                                                  IIC                                                                   G2
        Self-
         test                                                                      S-CAP             H-OUTPUT
                                                                                  SWITCH              BU2527A
                                                        VIDEO
                                                                                                 F
                                                                                 Buck
                                                                                 converter
                                                 HORIZONTZL &                    MTP5P25
                                                   VERTICAL
    CONTROL                                     SYNC.PROCESSOR                        H-Driver
       &                                        & B+ CONTROLLER                       BSN254A
      LED                            H              TDA 4841                                                        DYNAMIC
                                                                                                                      FOCUS
                                            V      IIC control
                     MICRO-PROCESSOR
                         WT62P2010B                                                   PWMIC L4990.
    EEPROM                                                                            Generate EHT
      24C16
                   OFF      DC                                                                         VERTICAL
                            O/P                 STANDBY                                              OUTPUT STAGE        MAIN
                                                SUSPEND                                                TDA8177F         BOARD
                     SWITCH MODE
      AC
                     POWER-SUPPLY
    INPUT                                                         DEGAUSSING                                             (30-92KHz)
                       TEA1504
