Image preview - the first page of the document
>> Download FC604801 documenatation <<
Text preview - extract from the document
Cucina Vacuum cleaner
FC6048/01
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION TECHNICAL INFORMATION
Features - Motor : AC motor 220 V / 230 V
- Application environment : Dry - Input power (Pmax 220 V) : 850 Watt
- Suction power (220 V) : 170 Watt
- Dust Chamber : Capacity 300 ml.
Safety - Filter : HEPA like
- This product meets the requirements regarding - Accessories : Crevice, brush, hose,
interference suppression on radio and TV. tube (3x), nozzle,
- After the product has been repaired, it should function shoulder strap
properly and has to meet the safety requirements as - Noise level (Lc) : 86.5 dB[A]
officially laid down at this moment. - Colour : High gloss olive black
- Weight : 1.4 kg
- Glass fuse : 6.3 x 32 mm T8AL 250 V
- SAP coding : FC6048/01
REPAIR INSTRUCTIONS
- No specific issues
L1a Switch Fuse
Thermal ASSEMBLY & DISASSEMBLY ADVICE
Fuse
- No specific issues
AC C1 M
OPTIONAL (accessories)
L1b
- No specific issues
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
