Image preview - the first page of the document
>> Download FC8397 documenatation <<
Text preview - extract from the document
Vacuum cleaner
FC8397
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- Colour version /02/A : Trans. Bonny blue - Push the button panel (item 1) sideways to release it from
- Electronically controlled motor speed the locking peg of the upper housing (item 3).
- Built-in cord winder - When the button panel has been removed, you have access
- Dustbag-full indicator in dust cover to the screws that need to be undone to disassemble the
- This product meets the requirements regarding housing.
interference suppression on radio and TV.
- After the product has been repaired, it should function C C
properly and has to meet the safety requirements as
officially laid down at this moment.
C
TECHNICAL INFORMATION
- Maximum air displacement : 33 l/sec.
- Maximum vacuum water column : 350 cm B
- Power consumption (IEC) 225V : 1800 W
- Dust storage capacity : 2 litres A A
- Cord length (depends on version) : 6.3 m C
- Filter system : 5 filters
- Dimensions cleaner : 37 x 28 x 23 cm - Lift the motor housing (item 26) out of the lower housing
- Net weight : 4.8 kg and take out the cord winder unit.
- Noise : 80 dB max. - To disassemble the cord winder, use TORX screwdriver no.
T10, which is one of a set consisting of T20; T15; T10;
OPTIONAL (accessories) T9; T8; T7 and T6 (code number 4822 395 50145).
- FC8032 Exhaust air filter 4822 015 70056
- HR6997 S-Cotton dustbag 8836 997 01010
- FC8021 S-Paper dustbag 4822 480 10113
- FC8022 S-Clinic dustbag 8838 022 01010
- FC8023 S-Anti odor dustbag 8838 023 01000
