Image preview - the first page of the document
>> Download FC8392LFL documenatation <<
Text preview - extract from the document
Vacuum cleaner
FC8392
L.F.L.
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- Colour version /01/A : Lime green - Push the button panel (item 1) sideways to release it from
- Built-in cord winder the locking peg of the upper housing (item 3).
- Dustbag-full indicator in dust cover - When the button panel has been removed, you have access
- This product meets the requirements regarding to the screws that need to be undone to disassemble the
interference suppression on radio and TV. housing.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as C C
officially laid down at this moment.
TECHNICAL INFORMATION C
- Maximum air displacement : 31 l/sec.
- Maximum vacuum water column : 350 cm
- Power consumption (IEC) 225V : 1300 W B
- Dust storage capacity : 2 litres
- Cord length (depends on version) : 6.3 m A A
- Filter system : 5 filters C
- Dimensions cleaner : 37 x 28 x 23 cm
- Net weight : 4.8 kg - Lift the motor housing (item 26) out of the lower housing
- Noise : 80 dB max. and take out the cord winder unit.
- To disassemble the cord winder, use TORX screwdriver no.
OPTIONAL (accessories) T10, which is one of a set consisting of T20; T15; T10;
T9; T8; T7 and T6 (code number 4822 395 50145).
- FC8032 Exhaust air filter 4822 015 70056
- HR6997 S-Cotton dustbag 8836 997 01010
- FC8021 S-Paper dustbag 4822 480 10113
- FC8022 S-Clinic dustbag 8838 022 01010
- FC8023 S-Anti odor dustbag 8838 023 01000
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
