Image preview - the first page of the document
>> Download FC8402 documenatation <<
Text preview - extract from the document
City Line Barcelona Vacuum cleaner
FC8402
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION - First remove the two screws
B of (item 15) hinge turn + 1 B
B
- Electronic controled motor rpm window. Remove (item 15)
- Cordwinder build-in with flat cord hinge turn + window from (item
- Dustbag-full indicator in dustcover 3) upper housing by means of a
flat instrument (e.g. screw driver) 2
- This product meets the requirements regarding
as shown (to prevent demage).
interference suppression on radio and TV.
The hinge turn + window has
- After the product has been repaired, it should function snaps which fits into the upper
properly and has to meet the safety requirements as housing. Vario / knob turn
officially laid down at this moment. (item 10 ) can now be separated
as shown in next drawing.
- Place the knob turn in line with
4
TECHNICAL INFORMATION B
the adjuster item 10A. Hook 3 B
- Maximum air displacement : 34 l/sec (item 15) hinge turn + window
- Maximum vacuum water column : 280 cm into the (item 3) upper housing.
Use the 2 screws (item B) to
- Power consumptio (IEC) 225V : 1400 W 2
fasten item 15 to item 3. Place
- Dust storage capacity : 2 litres the cover of vario / knob turn
- Cord length (depends on version) : 6m (item 10) in the correct way; 1
- Filter system : 6 filters only on one way possible.
- Dimensions cleaner : 37 x 28 x 23 cm
- Weight + accessoiries on board : 4.3 kg REPAIR INSTRUCTION
- Noise : 80 dB - Give attention that the contact fingers (item 45) are placed on
- Colour : Lavender the cord-winder shaft in such a way that the pressure point of the
cordwinder knob to the cord winderlever (item 40) is vertical.
- The spare parts have been standardized as much as possible.
DISASSEMBLY- AND RE-ASSEMBLY ADVISE - Component configuration on exploded view may differ in case of
- To open the appliance, first remove the screws A,B,C,D. specific versions, however, the actual components are distinguished
- To reach the motor remove the screws E. by means of code numbers.
- To disassemble the cordwider use Torx screw driver no T10, - Item 1 Cotton dustbag is used in those countries where paper
which is one of set consisting of : dustbags are not available
T20, T15, T10, T9, T8, T7 and T6 = 4822 395 50145. - Item 41 Cord-winder spring unit is provided with a long spring,
both long and short cords can be used in combination with this
spring.
- Cordwinder spring has to be tensioned till maximum minus
approx. 1,5 revolution.
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
