Image preview - the first page of the document



>> Download FC8438 documenatation <<

Text preview - extract from the document

                                                       City Line Moscow                                  Vacuum cleaner
                                                                                                                                FC8438




   Philips Domestic Appliances and Personal Care




  Service Manual
   PRODUCT INFORMATION                                                       DISASSEMBLY- AND RE-ASSEMBLY ADVISE
   - Colour: Pearl White                                                     - First lift and remove the knob and printed knob base and
   - Electronically controlled motor speed                                     then loosen mounting screws A.
   - Built-in cord winder
   - Dustbag-full indicator in dust cover
   - This product meets the requirements regarding
     interference suppression on radio and TV.
   - After the product has been repaired, it should function                                                         A                   A
     properly and has to meet the safety requirements as
     officially laid down at this moment.

   TECHNICAL INFORMATION                                                                                                 A
   -   Maximum air displacement               :   36 l/sec.
   -   Maximum vacuum water column            :   270 cm
   -   Power consumption (IEC)                :   1600 W                     - Lift the motor housing (item 26) out of the lower housing
   -   Dust storage capacity                  :   2l                           and take out the cord winder unit.
   -   Cord length (depends on version)       :   6m                         - To disassemble the cord winder, use TORX screwdriver no.
                                                                               T10, which is one of a set consisting of T20; T15; T10;
   -   Filter system                          :   5 filters
                                                                               T9; T8; T7 and T6 (code number 4822 395 50145).
   -   Dimensions of cleaner                  :   382 x 292 x 218 mm
   -   Dimensions of packaging                :   510 x 305 x 330 mm
   -   Net weight                             :   4.5 Kg
   -   Gross weight                           :   8,0 Kg
   -   Noise                                  :   80 dB

   OPTIONAL (accessories)
   - FC8021 S-paper dustbags                        8838 021 00000
   - FC8032 Exhaust AFS micro filter                4822 015 70056
   - HR6997 Sydney cotton dustbag                   8836 997 01010



Published by Philips Domestic Appliances and Personal Care       Printed in the Netherlands
