Image preview - the first page of the document
>> Download FC8604 documenatation <<Text preview - extract from the document Vacuum cleaner
FC8604
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION ACCESSORIES
- This product meets the requirements regarding - Nozzle : Reach & Clean all purpose nozzle
interference suppression on radio and TV. - Tubes : Metal lacquered telescopic tubes
- After the product has been repaired, it should function - Accessories : Brush and crevice nozzle
properly and has to meet the safety requirements as - Accessory storage : Accessory clip on tube
officially laid down at this moment.
- Coupling : Button coupling
TECHNICAL INFORMATION
OPTIONAL (accessories)
- Colour : Jamboree Yellow
- FC 8021 : S-bag Classic
- Power consumption : 1600W
- FC 8022 : S-bag Clinic
(IEC) 230V
- FC 8023 : S-bag Anti-Odour
- Maximum Air displacement :
37 l/s
- FC 8024 : S-bag Long Performance
- Vacuum :
280 mbar / 28.0 kPa
- FC 8032 : Super Clean Air filter,
- Type number dustbag :
FC8021
High-Flow AFS exhaust filter
- Duststorage capacity 3L:
- Cord length 7m:
- Fiter system :
5 Layer
Ultra Filtration System:
- Double layered compatible S-bagTM
- 2 layer permanent motor protection filter
- Super clean air exhaust filter
- Dimensions of cleaner : 252 x 299 x 457 mm
- Dimensions of packaging : 580 x 375 x 280 mm
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands
