Image preview - the first page of the document



>> Download FC8606B documenatation <<

Text preview - extract from the document

                                                                                                        Vacuum cleaner
                                                                                                                          FC8606
                                                                                                                              /B




   Philips Domestic Appliances and Personal Care




  Service Manual
   PRODUCT INFORMATION                                                   ACCESSORIES
   - This product meets the requirements regarding                       -   Nozzle                 :   All purpose wheeled nozzle
     interference suppression on radio and TV.                           -   Additional nozzle      :   Hard Floor nozzle
   - After the product has been repaired, it should function             -   Tubes                  :   Conical steel tubes
     properly and has to meet the safety requirements as                 -   Accessories            :   Crevice nozzle and small nozzle
     officially laid down at this moment.
                                                                         -   Accessory storage      :   Accessory clip on tube
                                                                         -   Coupling               :   Conical coupling
   TECHNICAL INFORMATION
   - Colour                             : Raven Black                    After sales accessoires.
   - Power consumption                  : 1600 W                         - FC8044                   : Super Clean Air HEPA filter
     (IEC) 230V
   - Maximum Air displacement           :
                                      37 l/s
                                                                         OPTIONAL (accessories)
   - Vacuum                             :
                                      280 mbar / 28.0 kPa
   - Type number dustbag                :
                                      FC8021                             -   FC 8021                :   S-bag Classic
   - Duststorage capacity             3L:                                -   FC 8022                :   S-bag Clinic
   - Cord length                      7m:                                -   FC 8023                :   S-bag Anti-Odour
   - Fiter system                       :
                                      5 Layer                            -   FC 8024                :   S-bag Long Performance
                                      Ultra Filtration System:           -   FC 8032                :   Super Clean Air filter,
     - Double layered compatible S-bagTM                                                                High-Flow AFS exhaust filter
     - 2 layer permanent motor protection filter
     - Super clean air exhaust filter
   - Dimensions of cleaner          : 252 x 299 x 457 mm
   - Dimensions of packaging        : 580 x 375 x 280 mm




Published by Philips Domestic Appliances and Personal Care   Printed in the Netherlands
