Image preview - the first page of the document
>> Download FC9017AB documenatation <<
Text preview - extract from the document
Universe Vacuum cleaner
FC9017
/A
/B
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- This product meets the requirements regarding - Open the appliance, first remove the exhaust filter grille
interference suppression on radio and TV. (item 20), and then remove the 2 screws - C of the switch
- After the product has been repaired, it should function control panel (item 15).
properly and has to meet the safety requirements as -
officially laid down at this moment. C 2x
C 9x 14a + b
TECHNICAL INFORMATION
- Colour /A : Lemon yellow
/B : Black
- Maximum air displacement : 37 l/sec.
- Maximum vacuum water column : 310 cm
- Power consumption (IEC) 230 V : 1500 W
- Duststorage capacity : 3L To remove the the panel, pos 14a + b must be removed by
- Type number dustbag : FC8021 using a screwdriver to separate the two covers from the panel
- Cord length (depends on version) : 7 metres as shown in the picture.
- Filter system : Paper dustbag - Undo and remove the 9 screws (T15) - C in the upper
: Exhaust AFS air filter housing (item 8). You will require a screwdriver with a
: Motor inlet filter 14.5 cm-long shank for this. Srewdriver 4322 009 08490
- Dimensions of cleaner : 460 x 315 x 270 mm can be used.
- Dimensions of packaging : 595 x 395 x 295 mm - The component configuration shown in the exploded view
- Net weight : 5.88 kg may differ in case of specific versions. The components are
- Gross weight : 9.135 kg distinguished by means of code numbers.
- When the repair is finished, check whether all functions of
OPTIONAL (accessories) the appliance work properly.
- FC8021 S-bags - To disassemble the cord winder, use TORX screwdriver no.
- FC8030 AFS-filter T10, which is one of a set consisting of T20; T15; T10; T9;
- FC8031 HEPA Air Filter T8; T7 and T6 (code number 4822 395 50145).
- FC8034 Upgrate kit Active Carbon Filter
- FC8042 Polishing nozzle
- FC8043 Turbo brush nozzle
