Image preview - the first page of the document
>> Download FC9018AB documenatation <<
Text preview - extract from the document
Universe Vacuum cleaner
FC9018
/A
/B
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- This product meets the requirements regarding - Open the appliance, first remove the exhaust filter grille
interference suppression on radio and TV. (item 20), and then remove the 2 screws - C of the switch
- After the product has been repaired, it should function control panel (item 15).
properly and has to meet the safety requirements as
officially laid down at this moment. C 2x
C 9x 14a + b
TECHNICAL INFORMATION
- Version /A : Accessories provided
with active coupling
/B : Accessories provided
with conical coupling
- Colour /A : Red persimmon
- To remove the the panel, pos 14a + b must be removed by
/B : Silver
using a screwdriver to separate the two covers from the panel
- Maximum air displacement : 37 l/sec. as shown in the picture.
- Maximum vacuum water column : 310 cm - Undo and remove the 9 screws (T15) - C in the upper
- Power consumption (IEC) 230 V : 1400 W housing (item 8). You will require a screwdriver with a
- Duststorage capacity : 3L 14.5 cm-long shank for this. Srewdriver 4322 009 08490
- Type number dustbag : FC8021 can be used.
- Cord length (depends on version) : 7 metres - The component configuration shown in the exploded view
- Filter system : Paper dustbag may differ in case of specific versions. The components are
: Exhaust AFS air filter distinguished by means of code numbers.
: Motor inlet filter - When the repair is finished, check whether all functions of
- Dimensions of cleaner : 460 x 315 x 270 mm the appliance work properly.
- Dimensions of packaging : 595 x 395 x 295 mm - To disassemble the cord winder, use TORX screwdriver no.
- Net weight : 5.88 kg T10, which is one of a set consisting of T20; T15; T10; T9;
- Gross weight : 9.135 kg T8; T7 and T6 (code number 4822 395 50145).
