Image preview - the first page of the document
>> Download FC9023 documenatation <<
Text preview - extract from the document
Universe Vacuum cleaner
FC9023
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- This product meets the requirements regarding - Open the appliance, first remove the exhaust filter grille
interference suppression on radio and TV. (item 20), and then remove the 2 screws - C of the switch
- After the product has been repaired, it should function control panel (item 15).
properly and has to meet the safety requirements as C 2x
officially laid down at this moment.
C 9x 14a + b
TECHNICAL INFORMATION
- Colour : Crystal white
- Maximum air displacement : 37 l/sec.
- Maximum vacuum water column : 310 cm
- Power consumption (IEC) 230 V : 1500 W
- Duststorage capacity : 3L - To remove the the panel, pos 14a + b must be removed by
- Type number dustbag : FC8021 using a screwdriver to separate the two covers from the panel
- Cord length (depends on version) : 7 metres as shown in the picture.
- Filter system : Paper dustbag - Undo and remove the 9 screws (T15) - C in the upper housing
: Exhaust HEPA air filter (item 8). You will require a screwdriver with a 14.5 cm-long
: Motor inlet filter shank for this. Srewdriver 4322 009 08490 can be used.
- Dimensions of cleaner : 460 x 315 x 270 mm - Item 8 Spare part is standard
supplied without a hole, you
- Dimensions of packaging : 595 x 395 x 295 mm
must drill a hole 2mm dia, so
- Net weight : 5.88 kg the air can reach the sensor on
- Gross weight : 9.135 kg the PCB via the pressure tube. ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
