Image preview - the first page of the document
>> Download FC9056 documenatation <<
Text preview - extract from the document
Vacuum cleaner
FC9056
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION ACCESSORIES
- This product meets the requirements regarding - Special nozzle : Super Parquet nozzle
interference suppression on radio and TV. - Nozzle : Tri-Active all purpose nozzle
- After the product has been repaired, it should function - Tubes : Metal lacquered telescopic tubes
properly and has to meet the safety requirements as - Accessories : Brush, crevice nozzle and
officially laid down at this moment. small nozzle
- Accessory storage : Active accessory storage bridge in
TECHNICAL INFORMATION handgrip
- Colour : Macaw green - Coupling : Button coupling
- Power consumption : 1600 W
(IEC) 230V OPTIONAL (accessories)
- Maximum Air displacement : 39 l/s - FC 8021 : S-bag Classic
- Vacuum : 280 mbar / 28.0 kPa - FC 8022 : S-bag Clinic
- Type number dustbag : FC8021 - FC 8023 : S-bag Anti-Odour
- Duststorage capacity : 3L - FC 8024 : S-bag Long Performance
- Cord length : 7m - FC 8025 : S-fresh scent granules
- Fiter system : Double layered - FC 8030 : Super Clean Air filter, High-Flow
compatible s-bagTM AFS exhaust filter
: 3 layer permanent motor
- FC 8031 : Super Clean Air HEPA filter,
protection filter
HEPA12 exhaust filter
: Super Clean Air
exhaust filter - FC 8041 : Replacement pads
Super Parquet nozzle
- Dimensions of cleaner : 449 x 324 x 250 mm
- Dimensions of packaging : 593 x 393 x 296 mm
- Net weight : 5.7 kg
