Image preview - the first page of the document



>> Download FC9150B documenatation <<

Text preview - extract from the document

                                                                                                          Vacuum cleaner
                                                                                                                          FC9150
                                                                                                                              /B




   Philips Domestic Appliances and Personal Care




  Service Manual
   PRODUCT INFORMATION                                                      ACCESSORIES
   - This product meets the requirements regarding                          - Nozzle                  : Tri-Active all purpose nozzle
     interference suppression on radio and TV.                              - Tubes                   : Metal lacquered telescopic tubes
   - After the product has been repaired, it should function                - Accessories             : Brush, crevice nozzle and
     properly and has to meet the safety requirements as                                                small nozzle
     officially laid down at this moment.                                   - Accessory storage       : Active accessory storage bridge in
                                                                                                        handgrip
   TECHNICAL INFORMATION                                                    - Coupling                : Button coupling
   - Colour                             : Dark Demin
   - Power consumption                  : 1800 W                            OPTIONAL (accessories)
     (IEC) 230V                                                             -   FC 8021               : S-bag Classic
   - Maximum Air displacement           :   40 l/s                          -   FC 8022               : S-bag Clinic
   - Vacuum                             :   290 mbar / 29.0 kPa             -   FC 8023               : S-bag Anti-Odour
   - Type number dustbag                :   FC8021                          -   FC 8024               : S-bag Long Performance
   - Duststorage capacity               :   4L                              -   FC 8030               : Super Clean Air filter, High-Flow
   - Cord length                        :   9m                                                          AFS exhaust filter
   - Fiter system                       :   Double layered                  - FC 8031                 : Super Clean Air HEPA filter,
                                            compatible s-bagTM                                          HEPA12 exhaust filter
                                        :   3 layer permanent motor
                                            protection filter
                                        :   Ultra Clean Air HEPA13
                                            exhaust filter
   - Dimensions of cleaner              :   472 x 324 x 276 mm
   - Dimensions of packaging            :   593 x 393 x 296 mm
   - Net weight                         :   6.3 kg




Published by Philips Domestic Appliances and Personal Care      Printed in the Netherlands
