Image preview - the first page of the document
>> Download FC9152B documenatation <<
Text preview - extract from the document
Vacuum cleaner
FC9152
/B
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION ACCESSORIES
- This product meets the requirements regarding - Special nozzle : Super Parquet nozzle
interference suppression on radio and TV. - Nozzle : Tri-Active all purpose nozzle
- After the product has been repaired, it should function - Tubes : Metal lacquered telescopic tubes
properly and has to meet the safety requirements as - Accessories : Brush, crevice nozzle and
officially laid down at this moment. small nozzle
- Accessory storage : Active accessory storage bridge in
TECHNICAL INFORMATION handgrip
- Colour : Translucent Deep Red - Coupling : Button coupling
- Power consumption : 1800 W
(IEC) 230V OPTIONAL (accessories)
- Maximum Air displacement : 40 l/s - FC 8021 : S-bag Classic
- Vacuum : 290 mbar / 29.0 kPa - FC 8022 : S-bag Clinic
- Type number dustbag : FC8021 - FC 8023 : S-bag Anti-Odour
- Duststorage capacity : 4L - FC 8024 : S-bag Long Performance
- Cord length : 9m - FC 8030 : Super Clean Air filter, High-Flow
- Fiter system : Double layered AFS exhaust filter
compatible s-bagTM - FC 8031 : Super Clean Air HEPA filter,
: 3 layer permanent motor HEPA12 exhaust filter
protection filter
- FC 8041 : Replacement pads
: Ultra Clean Air HEPA13
Super Parquet nozzle
exhaust filter
- Dimensions of cleaner : 472 x 324 x 276 mm
- Dimensions of packaging : 593 x 393 x 296 mm
- Net weight : 6.3 kg
