Image preview - the first page of the document
>> Download FC9166A documenatation <<
Text preview - extract from the document
Vacuum cleaner
FC9166
/A
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION ACCESSORIES
- This product meets the requirements regarding - Remote control : Infra red remote control
interference suppression on radio and TV. - Nozzle : Tri-Active all purpose nozzle
- After the product has been repaired, it should function - Special Nozzle : Super Parquet Nozzle
properly and has to meet the safety requirements as - Tubes : Metal lacquered 3-piece telescopic tube
officially laid down at this moment.
- Accessories : Brush, crevice nozzle and small nozzle
- Accessory storage : Active accessory storage bridge in
TECHNICAL INFORMATION handgrip
- Colour : Smoked Black - Coupling : Button coupling
- Power consumption : 2000 W
(IEC) 230V OPTIONAL (accessories)
- Maximum Air displacement : 47 l/s
- FC 8021 : S-bag Classic
- Vacuum : 340 mbar / 34.0 kPa
- FC 8022 : S-bag Clinic
- Type number dustbag : FC8021
- FC 8023 : S-bag Anti-Odour
- Duststorage capacity : 4L
- FC 8024 : S-bag Long Performance
- Cord length : 9m
- FC 8030 : Super Clean Air filter, High-Flow
- Fiter system : Double layered AFS exhaust filter
compatible s-bagTM
- FC 8031 : Super Clean Air HEPA filter,
: 3 layer permanent motor
HEPA12 exhaust filter
protection filter
: Ultra Clean Air HEPA13
exhaust filter
- Dimensions of cleaner : 472 x 324 x 276 mm
- Dimensions of packaging : 593 x 393 x 296 mm
- Net weight : 6.3 kg
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
