Image preview - the first page of the document



>> Download FC9209B documenatation <<

Text preview - extract from the document

                                                                                                           Vacuum cleaner
                                                                                                                             FC9209
                                                                                                                                 /B




   Philips Domestic Appliances and Personal Care




  Service Manual
   PRODUCT INFORMATION                                                       ACCESSORIES
   - This product meets the requirements regarding                           - Special nozzle            : Turbo Brush nozzle and
     interference suppression on radio and TV.                                                             Super Parquet nozzle
   - After the product has been repaired, it should function                 - Nozzle                    : Tri-Active all purpose nozzle
     properly and has to meet the safety requirements as                     - Tubes                     : Metal lacquered telescopic tubes
     officially laid down at this moment.                                    - Accessories               : Brush, crevice nozzle and
                                                                                                           small nozzle
   TECHNICAL INFORMATION                                                     - Accessory storage         : Active accessory storage bridge in
   - Colour                             : Black                                                            handgrip
   - Power consumption                  : 1800 W                             - Coupling                  : Button coupling
     (IEC) 230V
   - Maximum Air displacement           :   37 l/s                           OPTIONAL (accessories)
   - Vacuum                             :   285 mbar / 28.5 kPa              - FC 8031                   : Super Clean Air HEPA filter,
   - Duststorage capacity               :   2L                                                             HEPA12 exhaust filter
   - Cord length                        :   9m
   - Fiter system                       :   HEPA cyclone-filtration
                                            system
                                        :   Permanent motor
                                            protection filter
                                        :   Super Clean Air
                                            HEPA12 exhaust filter
   - Dimensions of cleaner              :   470 x 320 x 340 mm
   - Dimensions of packaging            :   590 x 390 x 380 mm
   - Net weight                         :   7.2 kg




Published by Philips Domestic Appliances and Personal Care       Printed in the Netherlands
