Image preview - the first page of the document



>> Download FC9226 documenatation <<

Text preview - extract from the document

                                                                                                         Vacuum cleaner
                                                                                                                           FC9226




   Philips Domestic Appliances and Personal Care




  Service Manual
   PRODUCT INFORMATION                                                       ACCESSORIES
   - This product meets the requirements regarding                           - Nozzle                  : Tri-Active all purpose nozzle
     interference suppression on radio and TV.                               - Additional Nozzle       : Super parquet nozzle and
   - After the product has been repaired, it should function                                             Turbo nozzle
     properly and has to meet the safety requirements as                     - Tubes                   : Metal lacquered telescopic tubes
     officially laid down at this moment.                                    - Accessories             : Brush, crevice nozzle and
                                                                                                         small nozzle
   TECHNICAL INFORMATION                                                     - Accessory storage       : Active accessory storage bridge in
   - Colour                             : Emperor red                                                    handgrip
   - Power consumption                  : 1800 W                             - Coupling                : Button coupling
     (IEC) 230V
   - Maximum Air displacement           :   37 l/s                           OPTIONAL (accessories)
   - Vacuum                             :   285 mbar / 28.5 kPa              - FC 8031                 : Super Clean Air HEPA filter,
   - Duststorage capacity               :   2L                                                           HEPA12 exhaust filter
   - Cord length                        :   9m
   - Fiter system                       :   HEPA cyclone-filtration
                                            auto-clean system
                                        :   Permanent motor
                                            protection filter
                                        :   Ultra Clean Air
                                            HEPA13 exhaust filter
   - Dimensions of cleaner              :   470 x 320 x 340 mm
   - Dimensions of packaging            :   590 x 390 x 380 mm
   - Net weight                         :   7.2 kg




Published by Philips Domestic Appliances and Personal Care       Printed in the Netherlands
