Image preview - the first page of the document
>> Download fc8734_01 documenatation <<
Text preview - extract from the document
Vacuum cleaner
FC8734/01
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION ACCESSORIES
- This product meets the requirements regarding - Nozzle : Tri-Active all purpose nozzle
interference suppression on radio and TV. - Tubes : Metal lacquered telescopic tubes
- After the product has been repaired, it should function - Accessories : Brush, crevice nozzle and small
properly and has to meet the safety requirements as nozzle
officially laid down at this moment. - Accessory storage : Active accessory storage bridge in
handgrip
TECHNICAL INFORMATION - Coupling : Button coupling
- Colour : Deep Red
- Power consumption : 1800 W (IEC) 230 V OPTIONAL (accessories)
- Maximum Air displacement : 33 l/s - FC8047/02 Filter Cylinder 109 mm + Motor inlet Filter
- Vacuum : 250 mbar / 25 kPa
- Duststorage capacity : 2L
- Cord length : 8m
- Fiter system : HEPA cyclone-filtration
system
: Permanent motor
protection filter
: HEPA exhaust filter
- Net weight : 6 kg
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
