Image preview - the first page of the document



>> Download fc9078 documenatation <<

Text preview - extract from the document

                                                                                                           Vacuum cleaner
                                                                                                                           FC9078




   Philips Domestic Appliances and Personal Care




  Service Manual
   PRODUCT INFORMATION                                                       ACCESSORIES
   - This product meets the requirements regarding                           -   Nozzle                : Tri-Active all purpose nozzle
     interference suppression on radio and TV.                               -   Additional Nozzle     : Turbo nozzle
   - After the product has been repaired, it should function                 -   Tubes                 : Metal lacquered telescopic tubes
     properly and has to meet the safety requirements as                     -   Accessories           : Brush, crevice nozzle and
     officially laid down at this moment.                                                                small nozzle
                                                                             - Accessory storage       : Active accessory storage bridge in
   TECHNICAL INFORMATION                                                                                 handgrip
   - Colour                             : Dark Denim                         - Coupling                : Button coupling
   - Power consumption                  : 1800 W
     (IEC) 230V                                                              OPTIONAL (accessories)
   - Maximum Air displacement           :   43 l/s                           -   FC8021                : S-bag Classic
   - Vacuum                             :   300 mbar / 30.0 kPa              -   FC8022                : S-bag Clinic
   - Type number dustbag                :   FC8021                           -   FC8023                : S-bag Anti-Odour
   - Duststorage capacity               :   3L                               -   FC8025                : S-fresh scent granules
   - Cord length                        :   7m                               -   FC8031                : Super Clean Air HEPA filter,
   - Fiter system                       :   Classic S-Bag                                                HEPA12 exhaust filter
                                            long performance                 - FC8038                  : Ultra clean air washable HEPA13
                                        :   3 layer permanent motor                                      exhaust filter
                                            protection filter
                                        :   Ultra clean air washable
                                            HEPA13 exhaust filter
   - Dimensions of cleaner              :   449 x 324 x 250 mm
   - Dimensions of packaging            :   593 x 393 x 296 mm
   - Net weight                         :   5.7 kg




Published by Philips Domestic Appliances and Personal Care       Printed in the Netherlands
