Image preview - the first page of the document
>> Download fc9073 documenatation <<
Text preview - extract from the document
Vacuum cleaner
FC9073
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION ACCESSORIES
- This product meets the requirements regarding - Nozzle : Tri-Active all purpose nozzle
interference suppression on radio and TV. - Additional Nozzle : Hard floor nozzle
- After the product has been repaired, it should function - Tubes : Metal lacquered telescopic tubes
properly and has to meet the safety requirements as - Accessories : Crevice nozzle and small nozzle
officially laid down at this moment.
- Accessory storage : Active accessory storage bridge in
handgrip
TECHNICAL INFORMATION - Coupling : Button coupling
- Colour : Dark Raven
- Power consumption : 1800 W OPTIONAL (accessories)
(IEC) 230V
- FC8021 : S-bag Classic
- Maximum Air displacement : 43 l/s
- FC8022 : S-bag Clinic
- Vacuum : 300 mbar / 30.0 kPa
- FC8023 : S-bag Anti-Odour
- Type number dustbag : FC8021
- FC8025 : S-fresh scent granules
- Duststorage capacity : 3L
- FC8031 : Super Clean Air HEPA filter,
- Cord length : 7m HEPA12 exhaust filter
- Fiter system : Classic S-Bag - FC8038 : Ultra clean air washable HEPA13
long performance exhaust filter
: 3 layer permanent motor
protection filter
: Ultra clean air washable
HEPA13 exhaust filter
- Dimensions of cleaner : 449 x 324 x 250 mm
- Dimensions of packaging : 593 x 393 x 296 mm
- Net weight : 5.7 kg
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
